• Model NO.：DX 840,760,1045,1025,1050
• Power Source：Electric
• Feature：Automation
• Certification：CCC, ISO9001, CE
• Warranty：12 Months
• Customized：Customized
• Advantage：Easy to Maintenance
• Condition：New
• Item Name：Dx Roof Crimping Forming Machine
• Feeding Material：Trapezoidal Roof Sheet Panel
• Feeding Thickness：0.2-0.8mm
• Forming Speed：2-4m,Min
• Crimping Radian：Adjustable by PLC Computer
• Control Part：Delta PLC Control with Inverter; Frequency Convert
• Curving Mold：Cr 12 High Quenching with High Temperaute 62
• Max Production Order：Three
• Special Design：Yes
• Machine Size：3000mm*1500mm*1600mm
• Transport Package：Fit for Container Loading
• Specification：DX 840 or as your panel drawing
• Trademark：DX
• Origin：China, Hebei
• HS Code：84552210
• Production Capacity：27 Sets Per Month

Automatic Color Steel Roof Sheet Curving Machine1

Cutting&Hydraulic type

Cut slide/ Double guide pillar2

Hydraulic motor powe

3kw-7.5kw

3

Cutting  drive

Decelerating motor + Chain drive  gear all by high-frequency

4

Length measurement

Encoder

5

Control System

Panasonic /Siemens /  Delta PLC

6

Chain Size

1inch/2inch

7

Main Frame

300mm/350mm H-Beam or 350mm

8

Backboard Thickness

17mm/200mm

9

Feeding Material

Better as your drawing or from our designer

10

Feeding Thickness

0.18mm-0.8mm

11

Effective width

Better as your drawing or from our designer

12

Productivity

8-12/min

13

Roll Station

3-4rows(according to different design)14Roller Diameter  70mm/75mm(depend on different design)15 Roller material45# steel 16Cutter material Cr12 mould steel heat-treated hardness of HRC = 60-62 degrees17

Overall Size

Size of our designer

18

Total Weight

2t-4t

3PLC: Ensuring high accuracy and easy to operate!Fully Automatic: Just
input length of the sheets and numbers of the piece you need,
then the machine
FAQ
1. Q:Are you manufacturer?
A:Yes, we focus on cold roll forming machine manufacture over 12 years.

2. Q: if you can accept OEM? Design and manufacture according our photo.
A: Yes, we can accept OEM,we owned expert engineer team, professional design CAD drawings and use famous brand components according your demands.

3. Q:What's the warranty for your machine?
A: we provide 2years guarantee and provide lifetime technical support.

4. Q:How many workers is needed for the machine operation
A: One worker is enough, the machine use automatic PLC control system.

5. Do you have after sales support?
A: Yes,Our engineer can supply remote-video technical support and online support teach your worker.

6. Q.Can you be responsible for transport?
A.Yes,we owned expert export team, we can arrangement for you to your destination port or address.

7. Q:What service can you provide before order?
A:About the pre-sale service, We provide professional solutions according your demands,such as design,technical parameter,delivery flow etc. At the same time, we can supply invitation letter for your visit our factory and showing the machine operationfor you .

8. Q: What is the after- sale service?
A: we will supply lifetime technical support,quick-wear parts within 2years,Also can provide field maintenance and repair service.

9. Q:Any other service?
A: We can help you purchase raw material for machine,help you check ship date,update for you ship date etc
