Intermediate Wire Drawing Machine with Online Annealer

HOOHA Co., LIMITED
  • Type：LW Pulley Type Metal Drawing Machine
  • Usage：Wire, Rope Wire, Prestressed Steel Wire
  • Metal Material：Copper
  • Outlet Diameter：0.1-1.2mm
  • Max.Inlet Wire Dia.：8mm
  • Block Dia.：500mm

Base Info

  • Model NO.：ZLT250,21
  • Max. Number of Block：21
  • Certification：REACH, RoHS, ISO
  • Condition：New
  • Wire Size：2.6-3.0mm
  • Wire Finished Diameter：0.4-1.2mm
  • Max Dies No.：17
  • Drawing/Take up Motor：AC55kw,AC11kw
  • Spool Bobbin Size：Sn500 Sn630 Option
  • Power Supply：380V,50,60Hz
  • Lubrication Capacity：100L,Min
  • Annealing Voltage：Max 65V
  • Transport Package：Wood Package
  • Specification：CE ISO SGS
  • Trademark：HOOHA
  • Origin：Dongguan
  • HS Code：8463102000
  • Production Capacity：5 Sets,Month

Description

Team of HOOHA serviceNameeducationPositionMainly responsible for projectSpecializing in projectwire drawing machine with annealingModelZLT250/17ZLT250/21power controldual inverterwire inlet diameter2.6-3.0mm2.6-3.0mmwire finished diameter0.4-1.2mm0.4-1.2mmmax wire speed1800m/min1800m/min max dies NO.1721mechanical elongation25%+18.7%18.4%+15%construction of the machine bodaycasting+steel plate welded and annealeddrawing capastantungsten carbidefix speed capastan diameter250mmdrawing/take up motorAC55kw/AC11kw spool bobbin sizeSN500 SN630 optiontransmission typegear drivetension adjustmentbuffer rod with air cylinder and fix systemautomatic control of take up by PIDmax loading capacity250kg(SN 500) or SN630 power supply380V/50/60Hzlubrication capacity100L/minlubrication typelubrication by full immersionbrake disk type brakeannealing capacity85 KVAannealing voltagemax 65V annealing current1000ASteam consumption10-12m³/h 0.2-0.3MPacoiling water  consumption12-18m³/h 0.2-0.25MPaair consumption20-30m³/h 0.4-0.6Mpadimensions9*3*3.5Mweight7000kgIntermediate Wire Drawing Machine with Online Annealer

3.GEM Spare Parts Brands:
Motor: Dongguan Motor , Teco, ABB, Siemens
Inverter : Japan Yaskawa, Siemens, Taiwan Teco
Temperature Control Meter: Japan RKC;
Auxiliary Relay: Japan Omron ;
Ammeter and Voltmeter: Taiwan Risesun ;
Indicator, Switch and Button: Taiwan TEND ;
Contactor: Taiwan Shihlin
Line Speed Meter: Taiwan FOTEK/Yangming
Bearing : NSK, SKF
Intermediate Wire Drawing Machine with Online Annealer
4.Afetr service
1).Delivery dates: 45 days
2).Payment: TT or L/C
3).Packing: Wood packing and PE plastic packing ensure the goods safety on the transportation.
4). Install and training service: 2 professional engineers who has over 5 years overseas install and cable manufacture training experience.
5) after service phone number online
Intermediate Wire Drawing Machine with Online Annealer
5.Contact information:

Phone: +8613763134250
Http//:hoohaco.en.made-in-china.com
http://hoohaco.en.made-in-china.com/
Add:No. Beice District, Humen Town,
Dongguan  City, Guangdong Province,China
Intermediate Wire Drawing Machine with Online Annealer
6.Where are we:
Hongkong airport to Humen by boat 2 hours
Guangzhou airport to Humen by car 2 hours
Shenzhen airport to Humen by car 1 hour
Guangzhou South high speed train station to Humen 20 minutes
Shenzhen North high speed train station to Humen 20 minutes.
Intermediate Wire Drawing Machine with Online Annealer
