High Quality 16 Heads Wire Drawing Machine

HOOHA Co., LIMITED
  • After-sales Service：12 Months
  • Warranty：12 Months
  • Type：LW Pulley Type Metal Drawing Machine
  • Usage：Wire, Rope Wire, Prestressed Steel Wire
  • Metal Material：Copper
  • Outlet Diameter：0.1-1.2mm

Base Info

  • Model NO.：16 heands
  • Max.Inlet Wire Dia.：8mm
  • Block Dia.：500mm
  • Max. Number of Block：21
  • Certification：REACH, RoHS, ISO
  • Condition：New
  • Wire Size：0.75-1.6mm
  • Wire Finished Diameter：0.2-0.5mm
  • Max Wire Speed：2000m,Min
  • Max Dies No.：17
  • Fix Speed Capastan Diameter：206mm
  • Spool Bobbin Size：300*215*270mm
  • Max Loading Capacity：50kg
  • Technical Service：Install,Train,Operate
  • Transport Package：Plastic Package
  • Specification：CE ISO SGS
  • Trademark：HOOHA
  • Origin：Dongguan
  • HS Code：8463102000
  • Production Capacity：5 Sets,Month

Description

digital readout buttonpower controldual inverterwire inlet diameter0.75-1.6mm0.95-1.65mm0.5-1.2mmwire finished diameter0.2-0.5mm0.15-0.4mm0.1-0.32mm max wire speed2000m/min2000m/min2000m/minmax dies NO.17(18)2424mechanical elongation15%+8.7%15%+13%13%+8.7%construction of the machine bodaycasting+steel plate welded and annealeddrawing capastanceramic coatedcapastan diameter242mm242mm242mm fix speed capastan diameter206mmdrawing/take up motorAC55kw/AC11kwspool bobbin size300*215*270mmtransmission typeimport advanced flat belt drivebobbin loading unloading typeexpansion shaft or single sfaft cone main motor15kw15kw11kw spooler motor4kwtension adjustmentweight type tension pulleyfix systemautomatic control of take up by PIDmax loading capacity50kglubrication capacity50L/minlubrication typesprayingbrake magnetic brake lubrication type for bearingwithout oilannealing control3 poles DC current outputannealing capacity30 KVA21 or 30 KVA21KVAannealing voltage0-57Vannealing current400A400A300Atotal power19kw+30KVA19kw+30KVA15kw+30KVApower source380V,50/60HZ Steam consumption6-9kg/h 0.2-0.3MPacoiling water  consumption4-8m³/h 0.2-0.25MPaair consumption15-25m³/h 0.4-0.6Mpadimensions3*2.5*2.3Mweight3000kg

Spare Parts Brands
Motor: Siemens
Inverter : Japan Yaskawa, Siemens, Taiwan Teco
Temperature Control Meter: Japan RKC;
Auxiliary Relay: Japan Omron ;
Ammeter and Voltmeter: Taiwan Risesun ;
Indicator, Switch and Button: Taiwan TEND ;
Contactor: Taiwan Shihlin
Line Speed Meter: Taiwan FOTEK/Yangming
Bearing : NSK


High Quality 16 Heads Wire Drawing MachineHOOHA team focus on the cable making and use solution supply chain.
