• Model NO.：HH-001
• Max. Number of Block：21
• Certification：REACH, RoHS, ISO
• Condition：New
• Wire Inlet Diameter：0.75-1.6mm
• Wire Finished Diameter：0.2-0.5mm
• Spool Bobbin Size：300*215*270mm
• Main Motor：15kw
• Spooler Motor：4kw
• Power Source：380V, 50,60Hz
• Dimensions：2.7*1.6*2m
• Weight：2100kg
• Transport Package：Wood Package
• Specification：CE ISO SGS
• Trademark：HOOHA
• Origin：Dongguan
• HS Code：8463102000
• Production Capacity：5 Sets,Month

wire drawing machineModel17DHA18DHASMD205SMD206control systemdigital readout button or LCD computer controlpower controldual inverterwire inlet diameter0.75-1.6mm0.8-1.6mm0.95-1.65mm1.0-1.65mmwire finished diameter0.2-0.5mm0.3-0.6mm0.15-0.4mm0.2-0.6mmmax wire speed2000m/min1800m/min2500m/min1800m/min max dies NO.17(18)182424mechanical elongation15%+8.7%18%+13%15%+13%construction of the machine bodayone block casted, leveled four shafts.drawing capastanceramic coated capastan diameter242mm242mm242mm226mmfix speed capastan diameter206mmspool bobbin size300*215*270mm transmission typeimport advanced flat belt driveflat belt+timing beltbobbin loading unloading typeexpansion shaft or single sfaft cone main motor15kw18.5kw15kw18.5kwspooler motor4kwtension adjustmentweight type tension pulleyfix systemautomatic control of take up by PIDmax loading capacity50kg lubrication capacity50L/minlubrication typesprayingbrake magnetic brakelubrication type for bearingwithout oilpower source380V,50/60HZdimensions2.7*1.6*2Mweight2100kg


Spare Parts Brands:

Motor: Dongguan Motor , Teco, ABB, Siemens
Inverter : Japan Yaskawa, Siemens, Taiwan Teco
Temperature Control Meter: Japan RKC;
Auxiliary Relay: Japan Omron ;
Ammeter and Voltmeter: Taiwan Risesun ;
Indicator, Switch and Button: Taiwan TEND ;
Contactor: Taiwan Shihlin
Line Speed Meter: Taiwan FOTEK/Yangming
Bearing : NSK, SKF



After service

1).Delivery dates: 45 days
2).Payment: TT or L/C
3).Packing: Wood packing and PE plastic packing ensure the goods safety on the transportation.
4). Install and training service: 2 professional engineers who has over 5 years overseas install and cable manufacture training experience.
5) after service phone number online


Professional and Strong Manufacture and Sells Team:Team of HOOHA serviceNameeducationPositionMainly responsible for projectSpecializing in project Industry working history    ( year )zanyang XiecollegeGeneral EngineerThe total project design and planning power cable machine15xioahua HucollegeVis general engineerThe total project design and planning net cable,data cable machine10Chnaghong ChengcollegeEngineerDrawings and after-sales serviceTeflon,Optical fiber cable machine25xiuwu ChencollegeGeneral EngineerThe total project design and planning copper drawing machine15lixin YuancollegeEngineerThe project design and planning coppwer wire making technical16zhenghai Qiucollegecable engineerAfter servicecable making and cable factory management servie15jinxin LiucollegeMarketing engineerAfter serviceelectrical engineer7xingguo TangHigh schoolElectrical engineerAfter serviceelectrical engineer10changqiang LiHigh schoolMaintain engineerAfter servicemachina maintain and install service10haipin LiUniversityEngineering director Marketing and salesproject consulting 8sen YangUniversityEngineering translatorMarketing and salesproject consulting 5
