• Model NO.：Hydraulic curving machine
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Product Name：Hydraulic Curving Machine
• Main Motor Power：1.5kw Servo Motor
• Hydraulic Power：5.5kw
• Transport Package：No Packing
• Trademark：SAIBO
• Origin：Jiangsu, China
• HS Code：84552210
• Production Capacity：300sets,Year

NoSpecification of the material1Suitable MaterialGI/PPGI2Width of the raw materialBased on the purlin sizes.3Thickness0.3-0.8mm
Machine Detailed Parameters:Curving machine1. Machine adopt servo motor feeding of the sheet, 1.5kw servo motor.
2. Feeding press material: SAE1045 with quenching and tempering.
3. CR12 HRC55-60 surface with chrome.Hydraulic System


1. Hydraulic power: 5.5kw
2. Working pressure: 12Mpa adjustable
3. Solenoid valve: 1 group
4. Hydraulic oil: 46# hydraulic oil
5. Quantity :1
 Computer Control Cabinet


1. Programmable setting of profile length and quantity
2. Operating system language: English and Chinese
3. Voltage, Frequency, Phase: 380 V, 50 Hz, 3Phase
4. Computer used to control length & quantity.
5. Machine will automatically cut to length and stop when required quantity is achieved
6. Length inaccuracy can be amended easily.
7. Control panel: Button-type switch and touch screen
Main Features
1. Simple structure in linear type ,easy in installation and maintenance.
2. Adopting advanced world famous brand components in pneumatic parts, electric parts and operation parts.
3. Running in a high automatization and intellectualization, no pollution
4. No need foundation, easy operation

Warranty: 1 year warranty from date of shipment
Guarantee:1: Guaranteed against malfunctions due to manufacturing defects for 1 year after date of shipment. Repairs will be made free of charge.
2: Repairs will not be performed free of change even during the guarantee period in the follow circumstances
-  Damage occurs due to a natural disaster
-  Malfunction occurs due to user error
-  Malfunction occurs due to modifications
-  Malfunction occurs due to further movement or shipment after installation
3: Air ticket, transportation cost, hotel, meals and 100$ per day shall be for purchaser's account if manufacturer's engineer has to be send to purchaser's factory to maintain the machine during the guarantee period.
