• Model NO.：KIH Series
• Advantage：Use Widely
• Condition：New
• 60kw：30-80kHz
• Processing Object：Metal
• Molding Style：Forging
• Transport Package：Wooden Cases
• Trademark：DuroWelder
• Origin：China & USA
• HS Code：8514400090
• Production Capacity：1000 Sets,Month

Basic Info.

Model NO. KIH Series Advantage Use Widely Condition New 60kw 30-80kHz Processing Object Metal Molding Style Forging Transport Package Wooden Cases Trademark DuroWelder Origin China & USA HS Code 8514400090 Production Capacity 1000 Sets/Month

Product Description

KIH-60AB High Frequency Induction Heating Machine
Main characteristics:

1. MOSFET and Inverting technologies of First generation been used;
2. Simple structure and light weight;
3. Simple to operate, a few minutes is enough to learn it;
4. Simple to install, Installation can be done by unprofessional person very easily;
5. Advantages of the model with timer: The power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability;
6. The saparated models are designed to fit the dirty surrounding of some cases

Applications:
Heat treatment
Quenching(gear quenching, scissors quenching, hammer surface quenching)
Forging(rod hot forging, drill tip heat shaping)
Melting(gold, silver, copper forging)
Soldering and brazing(solder copper pipe and aluminum pipe, diamond blade tool brazing)

Type	KIH-60AB
Work power	3×380V/50-60HZ
The range of operating voltage	340V-420V(370-450)V AC
Output power	60 KW
Fluctuating frequency	30-80KHZ
Output current	400-3200A
Timing (Heat time\ Retain time \ Cool time)	1-99S
The flow rate of cooling water	0.2Mpa 9L/Min
Water temperature protection point	40ºC
Duty cycle	100% (40degree room temperature)
Weight	Mainparts:70Kg extension:48kg
Size	Main parts:800*470*560mm Extension: 500*310*410mm
