• Model NO.：YX155-280-840
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Color：Blue and Yellow
• Transport Package：Sea Packing
• Specification：CE SGS
• Trademark：SAIBO
• Origin：China
• HS Code：84552210
• Production Capacity：300set,Year

Item NO
Description
Offered specification1.1Roll Forming MachineYX1531.2Material Width1500mm1.3Rolling Speed12-15m/min(not include cutting time)1.4Rolling Thickness0.6-1.5 mm1.5Material TypePre-painted GI1.6Control SystemPLC  (Panasonic) as list in the note1.7Un Coiler10T hydraulic decoiler with coil car1.8Roller StationsAbout 42stations
According to the final design1.9Roller Material45# forged steel,  coated with chrome1.10Shaft Material and DIA¢115mm, material is 45# forge steel1.11Main Motor Power45kw(15kw*3)1.12Hydraulic Station Power7.5kw1.13Hydraulic Pressure20Mpa1.14Material Of CuttingCr12Mov quenching 58-62ºC1.15Tolerance3m+-1.5mm1.16Electric Source380V, 50HZ,3 phase
Also can satisfy customer's require1.17Machine TypeNew station1.18Way Of Drive1.2 inch double chains1.19Color Of The MachineYellow and blue1.20Size of the machineL*W*H  30m*2.3m*1.8m1.21Container Need3 x40 feet GP

4. Packing & Delivery
Deliver time: take goods after receive deposit 60 days
Packing: suitable of ocean transportation

5. Warranty
Warranty: 1 year warranty from date of shipment
Guarantee:
1: Guaranteed against malfunctions due to manufacturing defects for 1 year after date of shipment. Repairs will be made free of charge.
2: Repairs will not be performed free of change even during the guarantee period in the follow circumstances
-  Damage occurs due to a natural disaster
-  Malfunction occurs due to user error
-  Malfunction occurs due to modifications
-  Malfunction occurs due to further movement or shipment after installation
3:Air ticket, transportation cost, hotel, meals and 100$ per day shall be for purchaser's account if manufacturer's engineer has to be send to purchaser's factory to maintain the machine during the guarantee period.

6. Payment Term
   30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment

ATTENTION: The profile of the panel is according to the clients!
