Hydraulic Automatic Roll Forming Machine Raw Materials Coils Decoiler with Car

Cangzhou Dixin Roll Forming Machine Co., Ltd.
  • Type：Rolling Machine
  • Forging Forming Method：Mold Forging
  • Power Source：Hydraulic Pressure
  • Feature：Automation
  • Certification：CCC, ISO9001, CE
  • Warranty：12 Months

Base Info

  • Model NO.：Hydraulic Automatic Decoiler
  • Customized：Customized
  • Advantage：Easy to Maintenance
  • Condition：New
  • Color：Blue
  • Chain：1 Inch
  • Forming Steps：23
  • Roller：High Grade 45# Steel
  • Shaft：75mm
  • Material：Galvanized,Aluminum,Color Steel Sheet
  • Thickness：0.3-0.8mm
  • Middle Plate：14mm
  • Hydraulic System：PLC Computer
  • Electric Motor：4kw
  • Transport Package：Nude, Covered with Plastic Film
  • Specification：CE, SGS
  • Trademark：DIXIN
  • Origin：Botou, Hebei, China
  • HS Code：84552210
  • Production Capacity：30 Sets,Month

Description

Main parameter 1Suitable to processGalvanized/Aluminum/Color steel sheet2Width of plate1250mm3Thickness of plate0.3-0.8mm4RollersHigh grade 45# steel, with hard chrome plating5Forming steps166Sprocket chain1.5 inch7Pump station power4kw8Shaft75mm, high grade 45# steel, heat treatment9Hydraulic oil pumpCB-E31010WeightAbout 5.0 tons11Productivity8-12m/min12Cutting headCr12 mould steel with quenched treatment13Control systemTAIDA brand PLC control14Voltage380V 3Phase 60Hz15Motor power4kw16DimensionAbout 6.8m*1.5m*1.5m17Hydraulic pressure10-12mpa18Index error of length±1mm19The temperature range of working line-35-50°Above all the parameters can be changed exactly according to customer's requirements.
4. Advantage of DIXIN roll forming machineNo.DIXIN roll forming machine1High grade quality2Reasonable price3High efficiency4Low failure rate5Low energy consumption6Free after-sale service7Reliable working8Durable9Wide application10Beautiful appearance11Welcomed by all over the world customers12Professional foreign trade team13Mature technician team14Customize special type5. Want a free quotation for make budget?
Just send inquiry to me now!
6. We are your reliable partner!
We always do the best to make our machine perfect in every detail part.
Any pics or videos about machine, we can provide you.
7. Payment terms
30% T/T as the deposit when contract signed, 70% balanced before shipping.
8. Company information
Hydraulic Automatic Roll Forming Machine Raw Materials Coils Decoiler with Car

Welcome to our factory!

If you have any question, you can contact me!
