• Model NO.：HH-250,17
• Max.Inlet Wire Dia.：8mm
• Block Dia.：500mm
• Max. Number of Block：21
• Certification：REACH, RoHS, ISO
• Condition：New
• Certificate：ISO
• Motor：Germany-Siemens
• Bearing：Japan-NSK
• Inverter：Siemens
• Electric Element：Siemens and Omron
• Control Box：International Standard
• Transport Package：Plastic Package
• Specification：CE ISO SGS
• Trademark：HOOHA
• Origin：Dongguan
• HS Code：8479400000
• Production Capacity：3 Sets,Month

Type
HH-250/17
HH-250/21
Power control
Dual-inverter
Input wire
Φ2.6-Φ3.0mm
Φ2.6-Φ3.0mm
Output wire
Φ0.40-Φ1.2mm
Φ0.40-Φ1.2mm
Maximum line speed
1800m/min
1800m/min
Maximum number of dies
17
21
Mechanical elongation
25%+18.7%
18.4%+15%
Construction of the machine body
Casting +steel plate welding and annealing
Drawing capstan
Tungsten carbide
Final capstan
Φ250mm
Drawing/take-up motor
AC55kW/AC11kW
Take-up type
SN500(SN630)Φ500×Φ300×345
Drive
Gear drive
Tension adjustment
Buffer rod with air cylinder and rocker arm
Correction system
PIDAutomatic control of take-up by PID
Maximum copper load
200kg, 500kg
Power supply
380V, 50/60HZ
Volume of lubricant
100L/min
Lubrication of wire drawing
Lubrication by full immersion
Brake
Disk type brake
Annealing capacity
85KVA
Annealing voltage
Max-65V
Annealing current
1000A
Steam consumption
10-12m3/h, 0.2-0.30Mpa
Cooling water consumption
12-18m3/h, 0.2-0.25MPa
Air consumption
20-30m3/h, 0.4-0.6MPa
DimensionsL×W×H
9000×3000×3000mm
Weight
ca.7000kg
