• Model NO.：ZYYX Series
• Customized：Customized
• Advantage：Easy to Maintenance
• Condition：New
• Name：C Purlin Forming Machine
• Brand Name：Zhongyuan
• Model Number：Zyyx76-305
• Roller Material：Cr12 Mould Steel Being Quenched Treatment
• Shaft Diameter：82mm
• Total Weight：About 7500kg
• The Whole Line′s Size：9mx1.05mx1.4m (Lxwxh)
• Line Working Speed：About 10m,Min
• Rollers Material：Cr12 Mould Steel Being Quenched Treatment
• Transport Package：1*40ft Container
• Specification：CE SGS BV
• Trademark：zhongyuan
• Origin：China
• HS Code：84552210
• Production Capacity：10sets,Month

ItemSpecification
MaterialTypePre-painted steel coil & galvanized coilsThickness(mm)1.5 - 3.0Yield strength(mpa)23 5 -3 45Roller materialCr12 mould  steelForming speed(m/min)About 10-15Speed adjusting modeAC FrequencyRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mould steel Length measurement E ncoderControl mode Mitsubishi  PLCOperating modeButton +  Mitsubishi  Touch screenMain motor power(kw)15KWTotal power(kw)20.5KW
Components  of machineD ecoiler1set   F eeding & guiding device1setM ain roll forming machine1setH ydraulic cutting system1setC ontrolling system1setOutput  stacker 1set
Process flow
Decoiler - -  Feeding & Guiding -- Roll forming- -- Hydraulic Cutting -  Run out of  table



Why us?
1.  Customize roll forming machines since 2003.
2.  Capacity: 12-15 sets/month
3.  Delivery: in only 5-8 weeks for urgent order
4.  Company occupies 6650, in which 5650 for workshops
5.  Have our own tool center. 12 sets CNC machines.
6. Zhongyuan is a "All-in-house source"
   --from raw material to the final high-precision forming machine. We have our precise tooling center.
