Desktop Table Type CNC Plasma and Flame Cutting Machine
Shanghai Tayor Heavy Industry (Group) Co., Ltd.- Customized：Customized
- Layout：Coaxial
- Cutting Material：Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel
- Automatic Grade：Automatic
- Power Source：Electric
- Cutting Mode：Plasma Cutting
Base Info
- Model NO.：CNCTG
- Structure Type：Desktop, Table Type
- CNC Controller：Hypertherm, Lknc-3200
- Plasma Source：Hypertherm, Kjellberg
- Cutting Thickness：1-50mm
- Cutting Speed：50-9000mm,Min
- Transport Package：Plywood Case and Tray
- Specification：CE & ISO9001: 2008
- Trademark：TAYOR
- Origin：Shanghai, China
- HS Code：8456901000
- Production Capacity：1000 Sets Per Year
Description
Cutting Technical DataModel CNCTG1520 CNCTG1530 CNCTG2060 CNCTG2580 Effective Cutting area (mm) 1500x2000 1500x3000 2000x6000 2500x8000 Cutting Thickness(mm) Flame:5-60mm Plasma:1-50mm Basic components Cutting Mode Plasma and Oxy-Fuel/Flame Structure of working table Joint Section Drive Mode Servo motor, Dual-drive or Single-drive Cutting Torch Number Customization Driving Motor Panasonic/Yaskawa CNC Controller Hypertherm EDGE Pro/Micro EDGE Pro, LKNC-3200, SJTU-SK, Burny Available Plasma Power source Hypertherm, Kjellberg, Thermal Dynamics, ESAB Software Fastcam, SmartNest, Hypertherm Dust extraction Air duct or water table Other Data Operation language Multi-language Supply power voltage 3×380V±10% 50HZ/according to user's local condition Optional items Platen device, zinc powder marking device, punching device, laser point, air conditioner, etc.
