• Model NO.：0.4-4mm
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Name：Steel Coil Slitting Machine
• Steel Thickness：1.0-1.5mm
• Power：7.5kw+5.5kw
• Transport Package：Sea Packing
• Trademark：SAIBO
• Origin：China
• HS Code：84552210
• Production Capacity：300set,Year

Item NO

Description

Offered specification

1Roll Forming Machine

Steel coil slitting machine

2Coil width1250mm3Rolling Speed12-15m/min(not include cutting time)4Rolling Thickness1.0-1.5mm color steel5Control SystemPLC (Panasonic) as list in the note6Un Coiler5T hydraulic de-coiler7Roller Stations2 stations for feeding8Roller MaterialRubber roller9Shaft Material and DIA¢85mm, material is 45# forge steel10SlittingMaximum in 7 strips11Blades of slitting6sets of slitting12Main Motor Power7.5kw13Hydraulic Station Power5.5kw14Hydraulic Pressure12-16Mpa adjustable15Material Of SlittingCr12Mov quenching 58-62ºC16Structure Of The StationsWall panel17Tolerance3m+-1.5mm18Electric Source

380V, 50HZ,3 phase

According to customer's require

19Way Of DriveBy chain20Color Of The MachineYellow and blue21Container Need1x40 feet

Main Features

1. The structure is simple and the appearance of the machine is beautiful because we adopt the shape-steel structure and process as a whole after welding. It has the ability of strong loading and stable operation when running the machine.
2. All the components of machine are from brand-famous enterprise so that they ensure the machine normal function very effectively.
3. We adopt the automatic length-fixed forming and cutting to guarantee the length to be precise and the finished product clear without deforming.
4. It is very easy to install the equipment and suitable for producing in the factory.
5. The machine has features of low noise and high efficiency.
