• Model NO.：ZYYX
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Machines Weight：About 8t
• Certificate：CE
• Delivery Time：About 50 Days
• Control System：Mitsubishi PLC & Converter
• Operation Language：English or as Per Client`S Required
• Rollers Material：No.45 Forged Solid Steel with Hard Chrome
• Cutting Style：Automatic Hydraulic Cut to Length
• Guarantee Time：First Year Free, Lifetime Services
• Main Motor：7.5kw
• Shafts for Rollers：72mm Diameter Solid Steel
• Transport Package：1*40gp Container for One Machine
• Specification：CE ISO Soncap
• Trademark：zhongyuan
• Origin：China
• HS Code：84552210
• Production Capacity：15sets,Month

ItemSpecificationMaterialTypeColor steel sheetThickness(mm)0. 3 -0.7Yield strength(mpa)235 -345Roller material45#Chrome steelForming speed(m/min)About 1500-2000mm/min or 4-5m/min. For optionStep distanceAdjustable according to requirement (>=250mm)Speed adjusting modeAC FrequencyRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mold steel Length measurement EncoderControl mode Mitsubishi  PLCOperating modeButton +  Mitsubishi  Touch screenMain motor power(kw)7.5KW    (Depend on final design)Hydraulic station power 5.5K W   (Depend on final design)Total power(kw)11KWUncoiler's loading capacityMax. Capacity: 5000kgs
(can be increased to be 10T)Machine`s sizeAbout 11*1.6*1.5m  (Depend on final design)Machine weightAbout 8000kgs

Components of machine:Decoiler1set   Feeding & guiding device1setMain roll forming machine1setPressing device1setHydraulic cutting system1setControlling system1setRun out table 1set
Process flow:
Decoiler -- Feeding & Guiding -- Roll Forming-- Pressing--Hydraulic Cutting - Product to Run Out Table


Packing:
1. One 40feet container for loading one set machine with mechanical decoiler.
2. Main machine body and decoiler is load naked (tighten to container with steel wire rope).
3. Spare parts and operating tools are loading in tooling box.


Why us?
1.  Manufacturing roll forming machine since 2003
2.  With ISO,SGS,BV and CE certificate
3.  1 year quality warranty
4.  Introduced Mitsubishi PLC with touch screen. Friendly man-machine interaction.
5.  Technician can be sent to your factory to install the machine and train your workers
6.  Export to more than 20 countries.



We customize your machines! To customize machine, we would love to know:
1. Profile drawing
2. Raw material: the width(1250mm?), thickness(0.3-0.7mm?), and yield strength of steel coil.
3. Voltage: designed per your requirement
4. Configuration requirement: Hydraulic or manual decoiler/ stacker

Have no idea about them?
We will be glad to recommend the lacol popular profile for you----Just let us know your country!


Please feel free to contact us for more information!
