• Model NO.：HAFA-850
• Weigth：1700kg
• Thickness of Raw Material：0.009mm ---0.025mm
• Width of Raw Material：250-600mm
• Maximun Unwinding Diameter：600mm
• Inner Diameter of Raw Material Roll Core：75mm, 150mm
• Inner Diameter of Finished′paper Core：25mm,30mm,38mm
• Cutting Length of Roll：3m-300m
• Production Efficiency：2-3m,Second
• Air Pressure：0.5MPa
• Transport Package：Wooden Case
• Specification：4000mmx1550mmx1750mm
• Trademark：fitlifemac
• Origin：Jiangsu, Cn
• HS Code：7607119000
• Production Capacity：15sets,Month

Thickness of Raw Material)0.009-0.025Air Pressure0.5MpaWidth of Raw Material250-600mmOveral Dimension4000*1550*1750mmMaximun Unwinding Diameterφ600mmTotal Powerapprox 4.5KWInner Diameter of Raw Material Roll Coreφ75mm,φ150mmTotal Weightapprox 1700KgInner Diameter of Finished Product Roll Coreφ25mm,φ30mm,φ38 mmProduction Efficiency2-3m/sCutting Length of Roll3-300mDecoil Centering Stroke+/-20mm

1,Thickness of Raw Material: 0.009-0.025mm
2,Width of Raw Material: 250-600mm
3,Maximun Unwinding Diameter: φ600mm
4,Inner Diameter of Raw Material Roll Core: φ75mm,φ150mm
5,Inner Diameter of Finished Product Roll Core:φ25mm,φ30mm,φ38 mm
6,Cutting Length of Roll: 3-300m
7,Production Efficiency: 2-3m/sec
8.Decoil Centering Stroke: +/-20mm
9.Air Pressure: 0.5Mpa
10.Engine Model:
Siemens panel, Mitsubishi servo , Mitsubishi PLC, Omron meter counter
Traction Motor:Y100L -4 Asynchronous Motor
2.2Kw
Squirrel-cage Rotary Motor) : P60B 8200 Servo Motor
1.5Kw
Rotary Glue Motor : 100YCJ120-3AP Reduction Motor
120W
11.Magnetic Powder Brake: 25N.m
12.Magnetic Powder Cluch : 25N.m
13.Overal Dimension:Length4000mm ;Width:1550mm ;High: 1750mm
14.Total Power: approx 4.5KW
15.Total Weight: approx 1700Kg

 Technical Data:
Raw materials aluminum foils thickness- 0.01mm to 0.02mm
Max raw materials width - 500mm
Maximum unwind roll diameter -600mm diameter
Raw material mother roll core ID -75mm/150mm (core ID)
Finished Roll Rewinding Core ID -25mm/30mm/35mm
Slitting length finished roll control -3M to 330M
Producing Speed -2.5m/s
Unloading magnetic power brake -25N. M
Winding magnetic power clutch -12N. M
Electrical Power & Supply -4KW
Weight of machine -1800kg
Dimension of machine (L x W x H)-3600mm x 1400mm x 1910mm
Online Add to Basket

Application: The machine is equipment than can once complete gluing, winding length counting and cutting in the production of foil material. It is suitable for processing work of packing materials such as household aluminum foil, etc. It is mainly used in the sectors of refreshing, grilling and cleaning, etc. It can substitute plastic preservative film. It is the domestic progressive food hygiene cleaning equipment at present.
Performance Features of kitchen aluminum foil rewind machine:
1. The complete machine adopts Siemens PLC control and safety & reliability.
2. In service, material receiving, gluing, winding and cutting, etc. are all automation control.
3. Without glue, winding and decrement of production cost
4. The winding adopts automatic gear shifting control with higher effect.
5. Squierrelcage operation adopts servo control, exact positioning without accumulated error.
6. Rolling small shaft delivery mechanism and exact safety.
7. Wallboard structure and smooth stabilization.
8. Constant tension unwinding and winding stabilization.
After-sales Service Provided:Engineers available to service machinery overseas
We have much experience in this line. We have exported to Italy, Greece, Russia, the Middle East, etc. we have passed ISO9001:2000, Haccp, AAA. Our aluminum foil related products have passed FDA, SGS, TUV. Our machines passed CE.With advanced equipments, superior quality administers and toping working team, we can offer our customers high quality products and the finest services. We are looking forward to establishing long-term business relations with clients
