• Model NO.：aluminium frame profile linear profile
• Customized：Customized
• Advantage：Simple Structure
• Condition：New
• Name：Aluminium Frame Profile Linear Profile
• Forming Size：6500mm*1300mmx1200mm
• Weight：4t
• Made Board：16mm
• Big Frame：300h Steel Welding
• Drive：by Chain
• Chain Specifications：1.2 Inch
• Molding Shaft Dimension：75mm
• Axis Dimension：45# Steel
• Molding Number Rows：15 Rollers
• Transport Package：Simple Waterproof Fit for Ocean Ship, Need a 20 Gp
• Specification：ISO CE BV
• Trademark：DIXIN
• Origin：Botou City, Hebei Province
• HS Code：84552210
• Production Capacity：20 Set Per Year

Material of blade
Cr12,heat treatment 60-62°C
Shearing system
It is controlled by gear wheel oil pump. After filling the hydraulic oil into the hydraulic oil tank, the pumps drive the cutter machine to begin the cutting job.
The system includes a set of hydraulic tank, a set of hydraulic oil pump, two hydraulic pipes. And two sets of electromagnetism valves.
Power of the oil pump: 4kw
Hydraulic oil :40#

Electrical system

Screen display
5.7 inches TaiDa  screen
Main computer control cabinet
It adopts industrial computer to control. The target piece's length is adjustable and digit of it can be adjusted. Computed mode has two modes: automatic and manual one. The system is easy to operate and use.
Processing precision : within 1.00mm
It contains liquid crystal screen, programmer, transformer for the electronic machines and kits of every part.
Transducer brand isEURA
The seller should provide Chinese and English language screen.
 3.Components of line,work flow


1Direct Factory in China Since 20082Good design and professional engineers more than 20 years experience3CE SGS BV AS--- authentication available4Overseas service available/one year quality guarantee5Good credit6Many other designs available and special design available
Our Service
First,we can produce the special machine,send your drawing to us,we can design for you.

Second,if you buy our products,we also can help you to purchase the material,like color roll,the price is lower than you buy by yourself.

Third, we provide a one year warranty and lifelong technical support,we can send our technicians to you to give you on-site training.

Four,engineers available to service machinery overseas.

Five, if you come to visit our factory,we can book the room for you,car pick up to send.
We supply you 24-hour online service, welcome you contact online.


Contact: Bella Hao  Mobile: +86 18231737651
