• Model NO.：YX65-400-425
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Size：5800*1600*1500mm
• Weight：7000kgs
• Motor Power：7.5kw*2 Sets
• Hydraulic Power：2.2kw
• Forming Steps：13
• Effective Width：300mm,400mm,500mm
• Material Width：470mm,575mm,680mm
• Material Thickness：0.4-1.0mm
• Working Speed：8-14m,Min
• Voltage：380V,60Hz,3pH
• Transport Package：Standard Package for Export
• Specification：SGS
• Trademark：XHH
• Origin：Xiamen Port, China
• HS Code：84552290
• Production Capacity：20 Sets,Months

Basic Info.

Model NO. YX65-400-425 Customized Customized Advantage Use Widely Condition New Size 5800*1600*1500mm Weight 7000kgs Motor Power 7.5kw*2 Sets Hydraulic Power 2.2kw Forming Steps 13 Effective Width 300mm,400mm,500mm Material Width 470mm,575mm,680mm Material Thickness 0.4-1.0mm Working Speed 8-14m/Min Voltage 380V/60Hz/3pH Transport Package Standard Package for Export Specification SGS Trademark XHH Origin Xiamen Port, China HS Code 84552290 Production Capacity 20 Sets/Months

Product Description

Detail information of YX65-400-425 Standing Seam Roof Forming Machine with Straight and Tapered type are as follow:

1,Main Technic Data:

1.	Size	6500*1600*1500mm
2.	Weight	70000KGS
3.	Motor Power	7.5KW*2 sets
4.	Hydraulic Power	2.2KW
5.	Voltage	380V/60HZ/3PH
6.	Forming Steps	13
7.	Forming Speed	8-14m/min
8.	Effective Width	300mm, 400mm, 500mm
9.	Material of Width	470mm, 575mm, 680mm
10.	Thickness  for Aluminum sheets:	0.4-1.0mm
11.	Thickness for Colored Prepainted and Galvanized  Sheet	0.4-0.8mm
12.	Material for All Rollers	high grade no. 45 forged steel, plated hard chrome on the surface of rollers


2,Main Accessories:

(1) Main Forming Machine,
(2) 5 Tons Manual Uncoiler,
(3) PLC Computer Controlling System With Touching Screen,
(4) Hydraulic System,
(5) Hydraulic Forming Cutter,
(6) 3 Run Out Tables,
(7) Operation Instruction,
(8) Tool.
