High Speed Scroll Cutting Line for Tinplate

Anhui XuanHong CNC Technology Co., Ltd.
  • Customized：Customized
  • Thickness：0.15~0.5mm
  • Width：600~1200mm
  • Length：460~1200mm
  • Materials：Tinplate, Aluminum Band, Silicon Steel
  • Certification：ISO, SGS

Base Info

  • Model NO.：XE1200HB4-180
  • Specification：SGS
  • Trademark：Xuanen
  • Origin：Hangzhou, Zhejiang
  • HS Code：8462319000
  • Production Capacity：30 Set,Year

Description

Basic Info.

Model NO. XE1200HB4-180 Specification SGS Trademark Xuanen Origin Hangzhou, Zhejiang HS Code 8462319000 Production Capacity 30 Set/Year

Product Description

High Speed Scroll Cutting Line for metal roll
XE1200HB4-180



APPLICATION
          This production line is  for decoiling, leveling and shearing of  tinplate coil,aluminum band ,silicon steel sheet,cold rolled steel,galvanized band and copper etc.

It is an important equipment to reduce the production cost by decreasing the waste of coil material in making iron tank and cover. Adopting this scroll cutting line can help you to save coil material for about 3%-8%.


MAIN SPECIFICATIONS
             Cutting linear velocity:                   150m/min;
           Cutting frequency:                          180ps/min;
           Stacker loaded weight:                  2t;
           Height of stacker:                           460mm (including bracket);
           Length tolerance:                            ≤±0.25mm;
           Diagonal tolerance:                        ≤±0.15mm;
           Decoiling expansion range:        Φ450~φ520mm;
           Maximum od of coil material:      Φ1900mm;
           Maximum weight of coil material:16.8t (it can reach 19t within 1-2 hours);
           Occupation area:                            30.6×6.52m.
