Metal Flexible Hose Machine
BOBO Machine Co., Ltd.- Type:Rolling Machine
- Forging Forming Method:Mold Forging
- Power Source:Electric
- Feature:Automation
- Certification:ISO9001, CE
- Warranty:12 Months
Base Info
- Model NO.:Customized
- Customized:Customized
- Advantage:Use Widely
- Condition:New
- Applicaiton:for Sanitary Hose, Cable Hose, etc
- Suitable Material:Stainless Steel, Galvanized Steel
- Diameter:up to 6 Inch
- Strip Thickness:0.15-0.50mm
- Strip Width:8-25mm
- Forming Method:Spiral Forming
- Lock Profile:Single Lock or Double Lock
- Cutting Method:Manual Cutting
- Speed Control:Inverter Control
- Lubrication and Cooling:Automatic Recycling
- Transport Package:Woode Package
- Specification:ISO
- Trademark:BOBO
- Origin:China
- HS Code:8455229090
- Production Capacity:8sets,Month
Description
Basic Info.
Model NO. Customized Customized Customized Advantage Use Widely Condition New Applicaiton for Sanitary Hose, Cable Hose, etc Suitable Material Stainless Steel, Galvanized Steel Diameter up to 6 Inch Strip Thickness 0.15-0.50mm Strip Width 8-25mm Forming Method Spiral Forming Lock Profile Single Lock or Double Lock Cutting Method Manual Cutting Speed Control Inverter Control Lubrication and Cooling Automatic Recycling Transport Package Woode Package Specification ISO Trademark BOBO Origin China HS Code 8455229090 Production Capacity 8sets/MonthProduct Description
Metal Flexible Hose MachineMetal Flexible Hose Machine is continuously producing single swage metal flexible conduit by using stainless steel or galvanized steel, etc. The finished flexible conduit is widely used for shower hose, cable casing, electric hose,etc.
Feature of Metal Flexible Hose Machine
1.The flexibility is adjustable by change lock seaming
2.Automatic lubrication and cooling water recycling system
3.Adjustable lock forming roller for different thickness
4.Speed control by inveter to match forming and collecting speed
Main technical data of Metal Flexible Hose Machine
1 | Diameter Range | 3/8" to 4" |
2 | Strip width | 9.5-25.5mm |
3 | Strip thickness | 0.2-0.5mm |
4 | Forming speed | about 2m/min |
5 | Motor power | 2.2-3.0 KW x 2 |
6 | Dimension | 900 x 900 x 1200mm |
7 | Weight | 800-1200KG |
