• Model NO.：1006 485#
• Transport Package：Carton
• Specification：1006485
• Trademark：COLO
• Origin：China
• Production Capacity：3000piece,Month

Basic Info.

Model NO. 1006 485# Transport Package Carton Specification 1006485 Trademark COLO Origin China Production Capacity 3000piece/Month

Product Description

Ig06 Powder Injector Spare Parts Insert Sleeve 1006 485

COLO manufacturing, supplying, wholesaling and exporting powder coating machine spare parts,such as powder spray gun, gun,parts,circut board, powder hopper, powder injector,powder house etc.To satisfy the requirements of the clients.We provide customized solutions of the offered range per the specifications of clients.



Model: 1006485 powder injector



IG06 Powder injector - complete (pos. 1-13) 1007 780
Conveying air check valve unit (red marking) - complete (incl. pos. 6, 8, 9 and 12) 1005 589
 Supplementary air check valve unit (black marking) - complete (incl. pos. 7, 8, 9 and 13)
1005 690
Injector body - complete (incl. pos. 1, 2, 10 and 11) 1006 530
1 Injector body (without pos. 2) 1006 484
2 O-ring - Ø 16x2 mm 1007 794#
3 Insert sleeve - Teflon, complete 1006 485#
4 Hose connection - Ø 10-12 mm, complete (incl. pos 4.1) 1006 531
4.1 O-ring - Ø 16x1.5 mm 205 141#
5 Threaded sleeve 1006 483
6 Connector (conveying air) - NW 5.5  1004 366
7 Connector (supplementary air) - NW 5.5 1004 367
8 O-ring - Ø 11x1.5 mm 1000 532#
9 Filter element - Ø 9/4x27 mm 1003 698
10 Nozzle 1006 488
11 Nozzle fixation - complete (incl. pos. 11.1) 1007 792
11.1 O-ring - Ø 8x1 mm 1007 793#
12 Body (red) 1004 369
13 Body (black) 1004 370
16 Conveying air hose - Ø 8/6 mm (red) 103 500
17 Supplementary air hose - Ø 8/6 mm (black) 103 756
18 Quick release coupling for conveying air hose - NW5-Ø 8 mm 261 645
19 Quick release coupling for supplementary air hose - NW5-Ø 8 mm 261 637
Powder hose - 66 type, POE, Ø 16/11 mm, with conductive strip (standard) 105 139*#
Powder hose - 74 type, POE, Ø 15/10 mm, with conductive strip 1001 673*#
Powder hose - 75 type, POE, Ø 18/12 mm, with conductive strip 1001 674*#

Packing&Delivery
Packing: Carton
Delivery: according to quantity, uaually small order within 2days.
If you are looking for powder coating machine spare parts , Just contact us for further discuss!Thank you!
