| MILLING AND DRILLING |
| Max. drilling capacity......................................................16 mm |
| Spindle speed Milling/Drilling......................200-2500 rpm±10% |
| Spindle taper...........................................................................MT3 |
| Table Longitudinal...........................................................200 mm |
| Table cross travel.............................................................120 mm |
| Spindle box travel...........................................................200 mm |
| End mill capacity..............................................................16 mm |
| Face mill capacity............................................................50 mm |
| Max. distance spindle to table......................................200 mm |
| Table effective size.................................................450x120 mm |
| T-slot size..............................................................................8 mm |
| Motor output power........................................................1000 W |
| Overall dimension (LxWxH)............................570x520x1600 mm |
| Weight (Net/Gross)...................................................185/230 kg |
| Packing size (LxWxH)......................................800x760x1780 mm |
| GRINDING |
| Spindle speed Grinding..........................................2500 rpm±10% |
| Grinding wheel size............................................100x16x20 mm |
