380V/130A, DC Inverter Technology, IGBT Module Plasma Cutting Machine Cutter-Cut130/Lgk130

Shenzhen General Welder Technology Co., Ltd.
  • Customized：Non-Customized
  • Layout：Vertical
  • Cutting Material：Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel
  • Automatic Grade：Semi-Automatic
  • Power Source：Electric
  • Cutting Mode：Plasma Cutting

Base Info

  • Model NO.：Cut130,LGK130
  • Model Number：Cut100 or as Your Demands
  • Main Technology：IGBT Inverter Technology
  • Real Max Current(a)：130
  • Color：Any Color You Wanted
  • Package：Plain or Colorful Carton
  • Dimention of Carton(mm)：570*325*520
  • Workpiece Thickness(mm)：1.0-50.0
  • Base Material：Carbon Steel, Stainless Steel, Low-Alloy Steel
  • Warranty Time：1 Year
  • Transport Package：Standards Sea Carton or Customized
  • Specification：CE
  • Trademark：N,M
  • Origin：Shenzhen, Guangdong China
  • HS Code：8456901000
  • Production Capacity：as Order

Description

TypeLGK-130control modeIGBT inverterRated input voltageAC380VRated input current(A)31Rated input capacity(KVA)20.5Rated output current(A)130Cable cross-sectional areamains input(mm2)6power output(mm2)16ground wire(mm2)4Rated output voltage(V)135Duty cycle(%)100Rated no-load voltage(V)315Current adjustment range(A)40-130Quality cutting thickness (carbon steel)(mm)1~30Maximum cutting thickness (carbon steel)(mm)45Using plasma gasCompressed airGas pressure range(MPa)0.4-0.6Applicable air compressor capacity(m3)≥0.6Arc ignition modeHigh pressure non-contactEnclosure ratingIP21SInsulation ratingFCooling methodAirPower factor0.93Dimensions(mm)510*265*500Host weight(KG)40
