10t Hydraulic Decoiler with Coil Car

Zhangjiagang City Saibo Science & Technology Co., Ltd.
  • Name：10t Hydraulic Decoiler with Coil Car
  • Main Power：7.5kw
  • Hydraulic Power：5.5kw
  • Transport Package：Sea Packing
  • Specification：CE SGS
  • Trademark：SAIBO

Base Info

  • Model NO.：10Tons
  • Origin：China
  • HS Code：84559000
  • Production Capacity：1000set,Year

Description

1Total powerMotor power-7.5kw
Hydraulic power-5.5kw2Coil weight (Max)10000kg3Inner diameter470-550mm4Maximal out diameter1600mm5
 Oil cylinder dia120mm6
 Coil width (Max)1250mm7
 Working speed0-15m/min adjustable8
 Main motor power7.5KW AC motor9
 Hydraulic power5.5kw10
 Coil car weight (Max)10000kg
2. Specification of ComponentsNo Technical Specification & Remark 110 ton hydraulic decoiler
10t Hydraulic Decoiler with Coil Car

  • The decoiler speed can be match with the main machine.
  • The speed is controlled by the inverter inside the control box.
  • Decoiler can work automatically.
2Coil car
10t Hydraulic Decoiler with Coil Car

  • The coil car can work up/down and forward/reverse.
  • There are two lines to guide the coil car into the decoiler
3Hydraulic System
10t Hydraulic Decoiler with Coil Car



  • Hydraulic power: 5.5kw
  • Working pressure: 12Mpa adjustable
  • Solenoid valve: 1 group
  • Hydraulic oil: 46# hydraulic oil
  • Quantity :1



Warranty

  • Warranty: 1 year warranty from date of shipment
  • Guarantee:

1: Guaranteed against malfunctions due to manufacturing defects for 1 year after date of shipment. Repairs will be made free of charge.
2: Repairs will not be performed free of change even during the guarantee period in the follow circumstances
- Damage occurs due to a natural disaster
- Malfunction occurs due to user error
- Malfunction occurs due to modifications
- Malfunction occurs due to further movement or shipment after installation
3:Air ticket, transportation cost, hotel, meals and 100$ per day shall be for purchaser's account if manufacturer's engineer has to be send to purchaser's factory to maintain the machine during the guarantee period.
