Steel Roll Forming Machine with Standing Seam Metal Roofing Machine
Xiamen Xinhonghua Machinery Co., Ltd.- Dimension：6000*1800*1700mm
- Weight：7000kgs
- Motor Power：5.5kw*2
- Hydraulic Power：2.2kw
- Voltage：380V,50Hz,3pH
- Material Width：470mm,575mm,680mm
Base Info
- Model NO.：YX65-300-400-500
- Effective Width：300mm,400mm,500mm
- Material Thickness：0.4-1.0mm
- Forming Steps：13steps
- Type：Standing Seam Roofing Forming Machine
- Transport Package：Standard Export Packge
- Specification：SGS
- Trademark：XHH
- Origin：Xiamen of China
- HS Code：84552290
- Production Capacity：20 Sets,Month
Description
Basic Info.
Model NO. YX65-300-400-500 Effective Width 300mm,400mm,500mm Material Thickness 0.4-1.0mm Forming Steps 13steps Type Standing Seam Roofing Forming Machine Transport Package Standard Export Packge Specification SGS Trademark XHH Origin Xiamen of China HS Code 84552290 Production Capacity 20 Sets/MonthProduct Description
Forming Machine Standing Seam Roofing
Dimension:6000*1800*1700mm
Motor Power:5.5KW*2
Material Thinckness:0.4-1.0mm
The detail information of Forming Machine with Standing Seam Roofing,Standing Seam Roofing Forming Machine are as follow;
Main Technical Date:
| 1. | Dimension | 6000*1800*1700mm |
| 2. | Weight | 7000KGS |
| 3. | Motor Power | 5.5KW*2 |
| 4. | Hydraulic Power | 2.2KW |
| 5. | Voltage | 380V/50HZ/3PH |
| 6. | Material Width | 470mm,575mm,680mm |
| 7. | Effective Width | 300mm,400mm,500mm |
| 8. | Material Thickness | 0.4-1.0mm |
| 9. | Forming Steps | 13steps |
| 10. | Forming Speed | 8-14m/min |
Main Accessories:
1. Main standing seam roofing forming machine;
2. 5 tons manual decoiler;
3. Hydraulic system;
4. PLC computer controlling system with touch screen;
5. Hydraulic forming cutter;
6. Protetive Cover;
7. Operational manual;
8.tools.
