High Speed Metal Sheet CNC Plasma Cutting Machine

Jinan Zhongke CNC Equipment Co., Ltd.
  • Customized：Customized
  • Cutting Material：Carbon Steel, Plate
  • Processing Thickness：6-20mm
  • Control System：Start
  • Cutting Speed：0-8000mm
  • Motor：Stepper Motor

Base Info

  • Model NO.：1325
  • Plasma Current：100A,150A,200A
  • Transmission：Helical Rack
  • Guide Rail：Taiwan Hiwin Square Guide Rail
  • Bed Structure：Welded Steel Bed Structure
  • Material：Metal
  • Application：Metal Engraving Machinery, Metal Cutting Machine
  • Transport Package：Plywood Package
  • Specification：1300*2500mm
  • Trademark：ZK
  • Origin：Jinan Shandong
  • HS Code：8456901000
  • Production Capacity：100

Description

NumberDescriptionParameter1X,Y,Z Working Area1300x2500mm2Cutting thickness(40A)0.5-10mm;(120A)3-16mm;*(200A)3-25mm3X,Y Traveling Positioning Accuracy±0.02/300mm4Cutting Speed0-8000mm/min5Plasma GeneratorAmerican Cut-Mast6FrameWelded Structure7X, Y StructureHelical rack, HIWIN square guide Rail Linear Bearings8Working FormUntouched Arc Striking9Working Voltage3-Phase 380V10Control systemStartfire control system(optional: DSP)11SoftwareType312Document Transmission FormUSB Interface13Drive MotorsStepper System14G.W.980KGS15Packing Size7.1 CBMJinan Zhongke CNC Equipment Co.,Ltd
Address:Dongyang Industrial region, Hehua Road, Licheng District, Jinan, Shandong, China
