• Model NO.：Angle Roll Forming Machine
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Certificate：CE
• Controlling System：Mitsubishi PLC & Converter
• Operation Language：English or as Per Client`S Required
• Rollers Material：No.45 Forged Steel with Hard Chrome
• Cutter Material：Cr12 Mould Steel with Quench Treatment
• Cutting Style：Automatic Cut to Length
• Shafts for Rollers：Grand Twice, ID72mm Solid Steel
• Guarantee：First Year Free, Lifetime Services
• Cotrol System：Mitsubishi PLC & Converter
• Machine Type：Angle Forming Machine
• Transport Package：1*40gp Container for One Machine
• Specification：ISO; CE
• Trademark：zhongyuan
• Origin：China
• HS Code：84552210
• Production Capacity：15sets,Month


Technical parameter
 ItemSpecification
Raw MaterialTypePre-painted steel coil & galvanized coilsThickness(mm)0.3-1.0Yield strength(mpa)235Roller material45# steel , coated with ChromeShaft for rollers Solid shaft with 72mm,processed with cylindrical grinderForming speed(m/min)About 15-18Output speed(m/min)About 12 for 6m length sheetSpeed adjusting modeMitsubishi frequency transformerRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mould steelLength measurementNemicon EncoderControl modeMitsubishi PLCOperating modeButton + Mitsubishi Touch screenMain motor power(kw)4KW
Process flow
Decoiler -- Feeding & Guiding -- Roll forming---Hydraulic Cutting - product to run out table

Components of machine
 Decoiler (manual decoiler and hydraulic decoiler for option)1set  Feeding & guiding device1setMain roll forming machine1setHydraulic cutting system1setControlling system1setRun out table (auto. Stacker for option)1set
   About usWe are professional in making roll forming machines since 2003. Company occupies 6650, in which 5650 for workshops.1.  Capacity: 12-15 sets/month 2.  Delivery: in only 5-8 weeks for urgent order 3.  Have our own tool center. 12 sets CNC machines.4. Zhongyuan is a "All-in-house source"     --from raw material to the final high-precision forming machine. We have our precise tooling center.5.  You can rely on our team!       We have engineers with experience more than 15 years in metal forming industry.
  Get Free:"Send" below get profile drawing & design technical support by our 15 year experience technicians FOR FREE!
 FAQ:1) Q: Are you manufacturer or trading company?A: We are manufacturer and trading company . 2) Q: Do you provide installing and training overseas?A: Overseas machine install and worker training services are optional. 3) Q: How is your after sales support? A: We provide technical support on line as well as overseas services by skillful technicians.  4) Q: How does your factory do regarding quality control? A: There is no tolerance regarding quality control. Quality control complies with ISO9001. Every machine has to past testing running before it's packed for shipment. 5) How can I trust you that machines pasted testing running before shipping?A:  1) We record the testing video for your reference. Or,    2) We welcome your visit us and test machine by yourself in our factory. 6) Q: Do you sell only standard machines?A: No. Most machines are made to order. 7) Q: Will you deliver the right goods as ordered? How can I trust you?A: Yes, we will. We are Gold supplier of Made-in-China with SGS assessment (Audit report can be provided).
