Trapez Profile Steel Cold Roll Forming Machine

Hangzhou Zhongyuan Machinery Factory
  • Type：Rolling Machine
  • Forging Forming Method：Cold Roll Forming
  • Power Source：Electric
  • Feature：High Efficiency
  • Certification：ISO9001, CE
  • Warranty：12 Months

Base Info

  • Model NO.：ZYYX
  • Customized：Customized
  • Advantage：Work Flexible
  • Condition：New
  • Machine Color：Made-to-Order
  • The Third Party Inspection：SGS, BV
  • Rollers Material：No.45 Forged Steel, Plated with Hard Chrom
  • Shaft Diameter：72mm
  • Cutter：Cr12 Mould Steel Being Quenched Treatment
  • Cutting Type：Cut to Length
  • Operation Language：English or as Per Client`S Required
  • Controlling System：Mitsubishi PLC & Converter
  • Main Power：5.5kw
  • Name：Trapez Profile Steel Cold Roll Forming Machine
  • Transport Package：1 Piece of 40gp Container
  • Specification：CE SGS BV ISO
  • Trademark：zhongyuan
  • Origin：China
  • HS Code：84552210
  • Production Capacity：30set,Month

Description


ItemSpecification TypePre-painted steel coil & galvanized coilsMaterialThickness (mm)0.4-0.7 Yield strength (mpa)235-345Roller material45#Chrome steelForming speed(m/min)About 15Speed adjusting modeAC FrequencyRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mould steel Length measurementEncoderControl modeMitsubishi PLCOperating modeButton + Mitsubishi Touch screenMain motor power (kw)5.5 kw  (Depend on final design)Hydraulic station power 2.2 kw (Depend on final design)Total power (kw)7.7 kwUncoiler's loading capacityMax. Capacity: 5000kgs (can be increased to be 10T)Components of machineDecoiler1set  Feeding & guiding device1setMain roll forming machine1setHydraulic cutting system1setControlling system 1setRun out table  1set
Process flow:Decoiler -- Feeding & Guiding -- Roll Forming-- Hydraulic Cutting - Product to Run Out Table
1. Our strength

With Zhongyuan products you save time and money!
Zhongyuan is a "All-in-house source"
--from raw material to the final high-precision forming machine. We have our precise tooling center.
When roll forming machine must be delivered immediately, depending on customer`s features, we can manufacture and deliver machine in only 5-8 weeks.

You can rely on our team!
The dedicated staff at Zhongyuan is our key to success.
We have engineers with experience more than 15 years in metal forming industry.
Employees and their development are of fundamental importance to Zhongyuan.

Quality by Zhongyaun
Zhongyuan is certified according to the standards ISO 9001: 2008 and EN982: 2008, EN ISO12100-1: 2003, EN ISO 14121-1: 2007.
Our Integrated Management System comprises Quality, Environment, Employment and Health Protection. When it comes to safety, there are no compromises.

2. Certificate

CE; ISO; SONCAP


3. The third party inspection: SGS, BV
