• Model NO.：Production Line
• HS Code：8462991000
• Production Capacity：5000 Pieces,Year

Basic Info.

Model NO. Production Line HS Code 8462991000 Production Capacity 5000 Pieces/Year

Product Description

The series machines are used to press metal plate. With different dies, it could make various work-pieces, which are widely used in aeroplane, ship, auto, engineering machinery, electricity rod, transformer and other relative lines.

The machine is driven by hydraulic pressure and controlled by CNC. It could attain quick down, slow-down of ram, pressure steady while working, quick returning and intermediate stop functions. Also, it could be driven as inch, single & continuous ways. It could be operated either single or double ways.

The frame is welded by steel plate of good rigidity and strength.

The ram run smoothly. Reposition precision, anti-eccentric load, work-pieces made precision are high because the use of circulation around servo control against CNC + electrical-hydraulic proportion valves linear encoder.

The press in air and the one of different angles are available. The crowning device which is built into the table and controlled by CNC attain the precise deflection compensation.

Type	nominal pressure(KW)	length of table(mm)	distance between uprights(mm)	Throat depth(mmm)	Ram stroke(mm)	Ram stroke speed(mm/s)	Max. open height (mm)	Main motor power(KW)
2- SLJS Y-300/3200	2×3000	2×3200	2600	350	250	7	500	2×22
2- SLJS Y-300/4000	2×3000	2×4000	3200	350	250	7	500	2×22
2- SLJS Y-300/5000	2×3000	2×5000	4000	350	250	7	500	2×22
2- SLJS Y-300/6000	2×3000	2×6000	4800	350	250	7	500	2×22
2- SLJS Y-400/4000	2×4000	2×4000	3200	400	320	7	630	2×30
2- SLJS Y-400/5000	2×4000	2×5000	4000	400	320	7	630	2×30
2- SLJS Y-400/6000	2×4000	2×6000	4800	400	320	7	630	2×30
2- SLJS Y-400/7000	2×4000	2×7000	5100	400	320	7	630	2×30
2- SLJS K-500/4000	2×5000	2×4000	3200	1100	400	7	1000	2×37
2- SLJS K-500/5000	2×5000	2×5000	4000	1100	400	7	1000	2×37
2- SLJS K-500/6000	2×5000	2×6000	4800	1100	400	7	1000	2×37
2- SLJS K-500/7000	2×5000	2×7000	5100	1100	400	7	1000	2×37
2- SLJS K-650/5000	2×6500	2×5000	4000	1100	400	7	1000	2×55
2- SLJS K-650/6000	2×6500	2×6000	4800	1100	400	7	1000	2×55
2- SLJS K-650/7000	2×6500	2×7000	5100	1100	400	7	1000	2×55
2- SLJS K-650/8000	2×6500	2×8000	6100	1100	400	7	1000	2×55
2- SLJS K-800/6000	2×8000	2×6000	4800	1200	400	7	13 0 0	4 ×30
2- SLJS K-800/7000	2×8000	2×7000	5100	1200	400	7	13 0 0	4 ×30
2- SLJS K-800/8000	2×8000	2×8000	6100	1200	400	7	13 0 0	4 ×30
2- SLJS K-800/10000	2×8000	2×10000	7800	1200	400	7	13 0 0	4 ×30
2- SLJS K-1000/6000	2×10000	2×6000	4800	1 2 00	400	7	13 0 0	4 ×37
2- SLJS K-1000/7000	2×10000	2×7000	5100	1 2 00	400	7	13 0 0	4 ×37
2- SLJS K-1000/8000	2×10000	2×8000	6100	1 2 00	400	7	13 0 0	4 ×37
2- SLJS K-1000/10000	2×10000	2×10000	7800	1 2 00	400	7	13 0 0	4 ×37
2- SLJS K-1200/6000	2×12000	2×6000	4800	1 2 00	400	6	13 0 0	4 ×45
2- SLJS K-1200/7000	2×12000	2×7000	5100	1 2 00	400	6	13 0 0	4 ×45
2- SLJS K-1200/8000	2×12000	2×8000	6100	1 2 00	400	6	13 0 0	4 ×45
2- SLJS K-1200/10000	2×12000	2×10000	7800	1 2 00	400	6	13 0 0	4 ×45
2- SLJS K-1600/7000	2×16000	2×7000	5100	1 2 00	400	6	13 0 0	4 ×55
2- SLJS K-1600/8000	2×16000	2×8000	6100	1 2 00	400	6	13 0 0	4 ×55
2- SLJS K-1600/10000	2×16000	2×10000	7800	1 2 00	400	6	13 0 0	4 ×55
2- SLJS K-1600/12000	2×16000	2×12000	9100	1 2 00	400	6	13 0 0	4 ×55
2- SLJS K- 1800/6000	2× 1 8 000	2× 6000	4600	1200	600	6	1300	4× 5 5
2- SLJS K- 1800/7000	2× 18000	2× 7000	5600	1200	600	6	1300	4× 5 5
2- SLJS K- 1800/8000	2× 18000	2× 8000	6600	1200	600	6	1300	4× 5 5
2- SLJS K- 1800/9000	2× 18000	2× 9000	7600	1200	600	6	1300	4× 5 5
2- SLJS K- 1800/10000	2× 18000	2× 10000	8600	1200	600	6	1300	4× 5 5
2- SLJS K- 1800/12000	2× 18000	2× 12000	10000	1200	600	6	1300	4× 5 5
2- SLJS K- 1800/14000	2× 18000	2× 14000	11600	1200	600	6	1300	4× 5 5
2- SLJS K- 2000/6000	2× 20000	2× 6000	4600	1200	600	6	1400	4×75
2- SLJS K- 2000/7000	2× 20000	2× 7000	5600	1200	600	6	1400	4×75
2- SLJS K- 2000/8000	2× 20000	2× 8000	6600	1200	600	6	1400	4×75
2- SLJS K- 2000/9000	2× 20000	2× 9000	7600	1200	600	6	1400	4×75
2- SLJS K- 2000/10000	2× 20000	2× 10000	8600	1200	600	6	1400	4×75
2- SLJS K- 2000/12000	2× 20000	2× 12000	10000	1200	600	6	1400	4×75
2- SLJS K- 2000/14000	2× 20000	2× 14000	11600	1200	600	6	1400	4×75
2- SLJS K- 2400/6000	2× 24000	2× 6000	4600	1 3 00	600	5	1400	4×75
2- SLJS K- 2400/7000	2× 24000	2× 7000	5600	1 3 00	600	5	1400	4×75
2- SLJS K- 2400/8000	2× 24000	2× 8000	6600	1 3 00	600	5	1400	4×75
2- SLJS K- 2400/9000	2× 24000	2× 9000	7600	1 3 00	600	5	1400	4×75
2- SLJS K- 2400/1000	2× 24000	2× 10000	8600	1 3 00	600	5	1400	4×75
2- SLJS K- 2400/12000	2× 24000	2× 12000	10000	1 3 00	600	5	1400	4×75
2- SLJS K- 2400/14000	2× 24000	2× 14000	11600	1 3 00	600	5	1400	4×75
