• Model NO.：RAS
• Customized：Customized
• Advantage：Work Flexible
• Condition：New
• Guillotine：Italy Controller
• Transport Package：Applicable for Shipment
• Specification：6.5mm~20mm
• Trademark：SLJS
• Origin：Shanghai, China
• HS Code：84623990
• Production Capacity：500PCS,Year

Basic Info.

Model NO. RAS Customized Customized Advantage Work Flexible Condition New Guillotine Italy Controller Transport Package Applicable for Shipment Specification 6.5mm~20mm Trademark SLJS Origin Shanghai, China HS Code 84623990 Production Capacity 500PCS/Year

Product Description

MAIN PARTS:
1, Italy ARON hydraulic valve
2, USA VICKERS pump
3, Italy HT071 controller
4, 4 edge high carbon high chrome D2 blade

MAIN FEATURES:
1, Variable Rake angle adjustment (1° - 3° ).
2, Ball transfers on table.
3, Top driven cylinders.
4, Rapid blade gap adjustment.
5, 4 edge high carbon high chrome D2 quality shear blades
6, 39" front operated motorized back gauge.
7, Shadow line lighting & well designed finger guard for clear view of cutting line.
8, Safety footswitch operation. Top blade will automatically return to top position when foot is removed from pedal.
9, 1000mm side squaring arm with disappearing stops & inch/metric rule.
10, Standard control system is Italy HT071. Holand Delem DAC310 and Swiss DNC 60G are optional.
11, Independent clamping of individual hold downs.
12, Ball screw and servo motor are standard equipment.

Model No.	Max. shearing thickness(mm)	Max. shearing width(mm)	Shearing angle(degree)	Backguage stroke(mm)	Main motor(KW)	Weight(kg)	Length(mm)	Width(mm)	Height(mm)
RAS256	6.5	2480	1-3	750	7.5	3800	3140	1740	2040
RAS306	6.5	3050	1-3	750	7.5	5500	3750	1770	2150
RAS406	6.5	4000	1-3	750	11	7500	4830	1840	2100
RAS506	6.5	5000	1-3	750	11	8500	3140	1710	1620
RAS606	6.5	6000	1-3	750	11	14000	6480	2100	2300
RAS258	8	2480	1-3	750	11	4000	3040	1700	1700
RAS308	8	3050	1-3	750	11	5800	3860	1700	1700
RAS408	8	4000	1-3	750	11	8000	4640	1700	1700
RAS508	8	5000	1-3	750	11	11500	5400	2400	2000
RAS608	8	6000	1-3	750	11	16000	6480	2100	2350
RAS4010	10	4000	1-3	750	15	12000	4650	2100	2000
RAS6010	10	6000	1-3	750	15	24000	6500	2100	2300
RAS3713	13	3700	1-3	1000	18.5	13500	4350	1830	2390
RAS4013	13	4000	1-3	1000	18.5	15000	4850	1830	2390
RAS3016	16	33050	1-3	1000	22	15000	4010	1940	2830
RAS4016	16	4000	1-3	1000	22	16500	5010	1980	2830
RAS2520	20	2480	1-3.5	1000	37	17000	3440	1980	2830
RAS4020	20	4000	1-3.5	1000	37	22000	4850	2600	2400
RAS6020	20	6000	1-3.5	1000	37	38000	6700	3000	3000
