• Model NO.：QC12K
• Trademark：SLJS
• Origin：Shanghai, China
• HS Code：84623990
• Production Capacity：1000 PCS,Year

Basic Info.

Model NO. QC12K Trademark SLJS Origin Shanghai, China HS Code 84623990 Production Capacity 1000 PCS/Year

Product Description

Features of Hydraulic Swing Beam Shearing Machine:

1, High performance CNC hydraulic Swing Beam Shearing Machine

2, Holistic welding structure

3, Standard with ESTUN SA810G, with servo motor control X axes

3, Shearing times and shearing stroke are controlled by CNC system automatically

4, Blade clearance manual adjusting device

5, Backguage is driven by servo motor and performance ball screw and linear guide
work for backgauge.

6, Front support arms and standard protective guard

7, A set of standard blade



Max. shearing width(mm)	4000	2500	3200	4000	3200	3200	3200
Distance between upright(mm)	4220	2720	3420	4220	3460	3465	3485
Strokes(n/mm)	15	20	18	15	12	9	6
Back gauge stroke(mm)	600	600	600	600	600	800	800
Shearing angle(° )	1.5	1.5	1.5	1.5	1.5	1.5	2.5
Working table height(mm)	800	800	800	800	800	810	810
Throat depth(mm)	100	100	100	100	100	100	100
Main power(kw)	7.5	7.5	7.5	7.5	11	18.5	22
Oil volume(L)	290	240	290	290	290	550	550
Length(mm)	4652	3130	3840	4630	3900	3945	4100
Width(mm)	1660	1570	1610	1850	1680	2270	2300
Height(mm)	1800	1790	1810	1890	1840	2240	2515
Weight(kg)	7500	5500	6600	8900	8500	12500	15500
