• Model NO.：Gravity casting machine
• Transport Package：Plywood
• Specification：international standard
• Trademark：SEMC
• Origin：China
• HS Code：8501320000
• Production Capacity：10000,Year

Product NameGravity casting machineEquipment ConfigurationIt is mainly composed of the main engine (base, bed, opening and closing mechanism and lower ejection mechanism), hydraulic system and electrical control system.Equipment warranty periodThe quality guarantee period of the equipment is one year. If the equipment is operated and used according to normal conditions, it will break down. The supplier is responsible for repairing and replacing the parts (except the fragile parts). In case of damage caused by other abnormal operation reasons, the supplier is also responsible for handling, and the buyer shall bear the cost of the damaged parts.Performance Characteristics1.It is mainly composed of a frame, a combination mechanism, a lower ejection mechanism and a pedestal.

2.Mould fast locking system;

3.All valves and valves are imported brand name products.

4.The hydraulic system uses constant pressure variable piston pump to reduce overflow loss and save energy.

5.All cylinders adopt imported products, and the oil cylinder near the mould adopts high temperature resistant seals.

6.The PLC of German Siemens Company is used as the core of electrical control to realize the manual and automatic control of the machine.

7.The main electrical components are made by German Siemens or Schneider Company, and the control cabinet is air conditioned by cabinet.

8.Imported touch display unit can display the working state of the machine intuitively and clearly, and the faults in the running process. It is convenient to set and modify various parameters.Date Delivery60 days after signing the contract and receiving the advance payment. Main technical parameters of machineNo.Nameparameter valuesUnit1Movable panel size1000X800mm2Movable plate travel600mm3Minimum opening distance of moving and static plate300mm4Maximum opening distance of moving and static plate900mm5Opening force122KN6Top top output122KN7Lower top output125KN8Bottom ejection stroke200mm9Rack tilt angle0~90.10Upward tilt122X2=244KN11Working pressure of hydraulic system10MPa12Oil pump motor power18.5Kw
