Creator Industry CNC1570 CNC EDM Machine Tools
Creator Industry (Suzhou) Co., Ltd.- Model：CNC EDM Machine
- X/Y/Z Axis Travel：1500,700mm
- Work Head Travel：500mm
- Worktable Size：1600*900mm
- Woktank Inner Dimension：2150*1150*700mm
- Max Oil Tank Capacity：2300liter
Base Info
- Model NO.：CNC1570 CR6C 50A
- Max Electrode Weight：200kg
- Max Workpiece Weight：4000kg
- Machine Size：2500*2500*2400mm
- Machine Weight：6190kg
- Transport Package：Wooden Case
- Specification：CE,ISO9001,SGS
- Trademark：LEAD
- Origin：China
- HS Code：8456301010
- Production Capacity：30 Sets, Month
Description
3 V220.346 220.346 220.346 220.346 220.346 380.415 380.415 380.415 380.415 380.415 Input power KVA 7 10 15 20 30 Working voltage(No load) V 100 100 100 150 250 High voltage V 140 or 250 140 or 250 140 or 250 140 or 250 140 or 250 Min. ON TIME µ S 1 1 1 1 1 Min. OFF TIME µ S 1 1 1 1 1 Max. Cutting speed mm3/min 480 720 1050 1500 2500 Best surface finish µ mRa. 0.2 0.2 0.2 0.2 0.2 Min. Electrode wear rate % 0.3 0.3 0.3 0.3 0.3 Weight kg 210 248 360 490 700
| Model | Unit | CNC1570 |
| Table travel(X axis) | mm | 1500 |
| Table travel(Y axis) | mm | 700 |
| Quill travel(Z1 axis) | mm | - |
| Work head travel(Z2 axis) | mm | 500 |
| Work table dimensions(LxW) | mm | 1600x900 |
| Distance between plate and table | mm | 596-1084 |
| Work tank inner dimensions(WxDxH) | mm | 2150x1150x700 |
| Max. capacity of dielectric fluid | Liter | 2300 |
| Max. electrode weight | kg | 200 |
| Max. workpiece weight | kg | 4000 |
| Machine unit dimensions(WxDxH) | mm | 2500x2500x2040 |
| Machine unit weight | kg | 6190 |
