Color Steel Sheet Roof Ridge Cap Tile Roll Forming Machine
Xiamen Xinhonghua Machinery Co., Ltd.- Type：Rolling Machine
- Forging Forming Method：Cold Roll Forming
- Power Source：Electric
- Feature：Automation
- Certification：SGS
- Warranty：12 Months
Base Info
- Model NO.：YX35-400
- Customized：Customized
- Advantage：Work Flexible
- Condition：New
- Motor Power：4kw
- Hydraulic Motor Power：3.5kw
- Thickness：0.3-0.8mm
- Forming Steps：15 Steps
- Forming Speed：14--18m,Min
- Voltage：380V,50Hz,3pH
- Transport Package：Standard Export Package
- Specification：SGS
- Trademark：XHH
- Origin：Xiamen of China
- HS Code：8455229090
- Production Capacity：20 Sets
Description
The detail information of YX35-400 Color Steel Sheet Roof Ridge Cap Tile Roll Forming Machine,Ridge Cap Roll Forming Machine are as Follow:
1. The chart of process flow:
Decoiling--active feeding---forming---measuring lengh---cutting---product to stand
2. Main equipment:
Decoiler, main forming machine, hydraulic cutting, electric system(PLC), hydraulic system, product stand.
3. Technical parameters
1)Profile thickness: 0.3--0.8mm
2)inner tight decoiler
A. Coil inner diameter: 450mm--700mm
B. Max width of coiling: 1250mm
C. Max weight of loading: 5000kg
3)main forming machine
A. Shaft material: 45# steel, bearing steel outer diameter 85mm
B. Main motor power: 5.5kw
C. Forming speed: 14--18m/min
D. Voltage: 380V, 50Hz
E. Roller station: 15
4)cutting system
A. Hydraulic cutter
B. Blade and mould material: Cr12 steel with quenched treated HRC58-62°
C. Cutting system advanced hydraulic drive, after automatic cutting after forming.
5)control system
A. PLC:
B. Coder:
6)hydraulic system
A. Advanced hydraulic system
