• Model NO.：DX1000
• Feature：High Efficiency
• Certification：CCC, ISO9001, CE
• Warranty：12 Months
• Customized：Customized
• Advantage：Work Flexible
• Condition：New
• Name：720 Floor Decking Making Machine
• Manual Decoiler：Manual Expanding, Passive Uncoil
• Inner Diameter：460-520mm
• Outer Diameter：1400mm
• Weight Capacity of Decoiler：10t
• Diameter of Shaft：80mm
• Material of Shaft：High-Grade 45# Steel
• Chain：20A
• Motor Power of Forming Machine：11kw*2
• Forming Speed：10-15m,Min
• Transport Package：Water-Proof Packaging, Covered with Plastic Film
• Specification：DX688,720,750
• Trademark：DIXIN
• Origin：Botou Hebei China
• HS Code：84552210
• Production Capacity：20 Set Per Month

1.Processing material

aluzinc/galvanized steel/colored steel coil

2.Material thickness

Max2mm

3.Feeding width:

1200mm

4.Effective width

1000mm As design

5.Main motor power

30kw

6.Pump station power

7.5kw

7. Shaft diameter

100mm solid shaft ,Surface of roller coated with chrome 0.05mm thickness

8.Forming steps

20 steps

9.Main frame

400H Steel frame

10. Side plate thickness

20mm

11.Roller material

45 # forged material, high frequency quenching, hard chromium plating

12.Control systerm

Panasonic PLC control with touch screen,Mitsubishi frequency converter ,Encoder(Omron)

13.Cutting blade material

Cr12

14.Working speed

About 15-20m/min

15. Transmission way

1.5 inch double chain

16. Machine size (mm)

About 11.8m*1.6m*1.6m

17.Power supply

380v,3phase,50hz or accodring to customer request

18 Electric Pre- cutter

Add a motor with chain drive

3.Main Components:

No

Name

Qty

1

Main Rolling Machine

1set

2

10ton electric decoiler

4 set

3

Hydraulic Cutting

1set

4

PLC control system

1set

5

Electric motor 7.5kw*2

2set

6

Hydraulic Pump Station

1set

7

Output table

2sets

8

Spare parts

1 box

Cangzhou Dixin Roll Forming Machine Co.,ltd is a professional manufacturer and exporter which has its own factory and also cooperate with several production factories and associated enterprises, concerning with the design, development and production of cold roll forming machines,material of building. We specialize in the automated production line of sheet cold roll forming machines. We are able to provide an integral resolution schema of cold roll forming system through a combination of advanced system design and equipment. Based on our advanced research and commercial team, we are able to research and development, manufacturing and sale of standard and non-standard cold roll forming equipment for our clients world widely.

 Direct customers to our company personally test our equipment;

Our engineers accompanied the test machine until customer satisfaction;
Our engineers free of charge for customer training guide customers to operate and maintain equipment;
Customers can ask engineers to client countries for machine installation and commissioning, clients pay the flight cost and the cost of our engineer.

Q1. What's your payment terms and delivery time?
A1: 30% as the deposit by T/T in advance, 70% as the balance payment by T/T after your inspect the machine well and before delivery. Of course your payment terms are acceptable.

After we get down payment, we will arrange production. About 30-45 days for delivery.

Q2. Do you have after-sales support?
A2: Yes, we are happy to provide advice and we also have skilled technicians available across the world.

Q3. Do you sell only standard machines?
A3: No, most of our machines are built according to customers specifications, using top brand components.
Q4. What will you do if the machine is broken?
A4: We provide 12 months free warranty and free technical support for the whole life of any machine.
If the broken parts can't repair, we can send the new parts replace the broken parts freely, but you need pay the express cost by yourself. If it is beyond the warranty period, we can negotiate to solve the problem, and we supply the technical support for the whole life of the equipment.

Q5. Can you be responsible for transport?
A5: Yes, please tell me the destination port or address. we have rich experience in transporting.

Q6. How to visit your company?
A6: 1) Fly to Beijing airport, By high speed train From Beijing Nan to Cangzhou Xi (1 hour).
       2) Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick up you.
