Li Battery Production Line Machine Transfer Interval Cell Electrode Coater

XIAMEN TOB NEW ENERGY TECHNOLOGY CO., LTD.
  • Warranty：1year
  • Type：Continuous and Interval Coating
  • Certification：CE
  • Condition：New
  • MOQ：1 Set
  • Power：3pH ,380V,50Hz,

Base Info

  • Model NO.：TOB-ZST-300-12M
  • Guaranteed Coating Width：100~300mm
  • Coating Speed：Less Than or Equal to 2m,Min
  • Single Coating Thickness Range：50-200um
  • Minimum Interval Length：20mm
  • Transport Package：Standard Export Packing
  • Trademark：TOB
  • Origin：Fujian, China

Description

Suitable solid contentAnode S.C. 60%±20%Cathode S.C. 60%±20%(PVDF system)
S.C. 50%±5%(SBR system)Single-sided coating dry thickness errorWithin ±3umCoating methodDouble sides 3 sections, unequal intermittent transfer coating / second sides automatic tracking / continuous transfer coatingBase material running directionForward coating ,The base material empty foil movement Positive, reverse.Control pressure0 ~ 50NRectify deviationEPC control,stroke 80mmOven length12mMaterial qualitySUS304 stainless steel, Inner tank 1.0mm,outside tank 1.2mmWarrantyOne year limited warranty with lifetime support
