• Model NO.：sand blasting
• Customer Inspection：Accepted
• Transport Package：by Sea
• Specification：7m
• Trademark：Xinnuo
• Origin：China
• HS Code：84552200
• Production Capacity：500 Set Per Year

Technical parameters:  1Name of commodity & specificationglazed tile roll forming machine 2Main motor power4kw, 3 phase 3Hydraulic motor power3kw 4Hydraulic Pressure10-12MPa 5Voltage380V /3phase/ 50 HZ (or as your requirement) 6Control SystemPLC Delta Inverter 7Main Frame300mm H-Beam or 350mm 8Backboard Thickness14mm 9Chain Size20mm 10Feeding Materialcolor steel coils 11Feeding Thickness0.25-0.4mm 12Feeding Width900mm 13Effective width760mm 14Productivity8-12m/min 15Roll Station14 roll steps(according to different design) 16Roller Diameter70mm(depend on different design) 17 Roller material 45# steel 18 Cutter materialCr12 , quenched 19Cr-Plating Size0.05mm 20Overall Size8000×1200×1500mm 21Total Weight4.0T 22ComponentsManual Uncoiler-------------------1 set Guiding Platform------------------1 set Coil Strip Leveler------------------1 set Main Machine of Roll Forming------1 set Electric-Motor---------------------1 set Cutting Device--------------------1 set Hydraulic Station------------------1 set PLC Control-----------------------1 set Supporter Table-------------------1 set 23WorkflowManual decoiling----feeding and guiding----roll forming----cut to length----run out table  24Packagenude in the container 25Minimum order quantity1 set 26Payment termsT/T(30% T/T pay in advance, the remaining 70% pay before ship)  27Delivery time30  working days later after receiving the deposit All technical parameters can be changed, according to user's need.
