Compression Coiling Wire Spring Making Machine
Guangdong Yonglian CNC Equipment Technology Co., Ltd.- Control Type:CNC
- Axis Count:5 Axis
- Wire Diameter:1.5-4.0 mm
- Axis:5
- Servo Motor:Japan SANYO
- Transport Package:Wooden Case
Base Info
- Model NO.:YLSK-540
- Specification:1800kg
- Trademark:YLSK
- Origin:Dongguan
- HS Code:8463300000
- Production Capacity:300 Sets,Year
Description
Basic Info.
Model NO. YLSK-540 Specification 1800kg Trademark YLSK Origin Dongguan HS Code 8463300000 Production Capacity 300 Sets/YearProduct Description
TECHNICAL TECHNICAL PARAMETERS:
Model | YLSK-540 |
Wire diameter (mm) | Ø1.5~Ø4.0 |
Axis Count | 5 Axis |
Outside Diameter (mm) | Max 80 |
Max feeding Length | Unlimited |
Max feeding Speed | 0-110 m/min |
Program Storage | 2000 Max |
Instruction value of wire feed | ±0.01~±9999.99mm |
Instruction value of cam | ±0.10~±359.90 |
Servo motor of wire feed(kw) | 5.5 |
Servo motor of Up-cut (kw) | 2.0 |
Servo motor of down-cut (kw) | 2.0 |
Servo motor of cam (kw) | 2.0 |
Servo motor of wire pitch(kw) | 1.2 |
(mm) Machine size (LXWXH) | 1400×1050×1800mm |
Weight (kg) | 1800 |
Power | 380V 3-Phase |
FAQ
1. Q: Can you customize the machine for the customer?
A: Yes,we can.We also provide OEM for customer,if you need customize service,please contact us.
2. Q: What is the Min.Order?
A: One set.
3. Q: What is the payment term
A: The payment term is 30% deposit as PO confirmation ,and 70% after the shipment.We also accept other payment term.
Q: What is the delivery time?
A: Normally the delivery time of the machine is 10-15 days after receiving deposit.But it depends on machine model.Some of
them could be shipped within 10 days.
5. Q: What is the guarantee period of the machine?
A: The guarantee period is one year from the date of B/L.
