• Model NO.：CNC-860R

Basic Info.

Model NO. CNC-860R

Product Description

CNC-860R CNC Spring Rotary Machine

 The machine functions and features:
1. It combines the design of Jiangnan and manufacturing technique, the only one, and protected by patent.
2. The computer offers the language options of both Chinese and English,featuring easy operation and accurate positioning.Computer can control three to eight servo motor,all motor can be synchronous or run alone.
3. The precise detection and tracking device is utilized to stop automatically in case of unqualifed products.
4. The outside diameter and angles can be modified at any time according to the working condition on the fluorescent screen.
5. Automatic mechanical design of self-lubricating oil supply ensures the equipment operation for a long time.
6. In the event of the wireless,disconnection,tangled lines, automatic machine halt and automatic acceleration,make production efficient.
7. Processing scope includes torsion spring,straight spring,tension spring,rectangle spring,wire forming,volute spring,spring and various fancy spring,complex and special spring ,etc.



Technical Parameters:

Item	Parammter
Model	CNC-860R
Axis Count	5
Diameter Range	Ø2.0-Ø6.0mm
Feeding Length	±0.01-±9999.99
Wire Feed speed	0-110m/min
Feeding Length	Unlimited
Cam Setting Value	±0.1°-±359.9°
Cam Rotaion Speed	0-60RPM
Wire Feed Servo Motor	15KW
Cam Servo Moto	7.0KW
Quill Servo Motor	1.5KW
Rotary Servo Motor	7.0KW
Spinner Servo Motor	1.5KW
Power Ac	380V±10%V50Hz
Dimensions(L*W*H)	2420*1800*2100mm
Machine Weight	4500kg
