• Model NO.：24DHT
• Max.Inlet Wire Dia.：1.2mm-0.5mm
• Block Dia.：300mm
• Max. Number of Block：24
• Certification：REACH, RoHS, ISO
• Condition：New
• Wire Size：1.2mm-0.5mm
• Wire Finished Diameter：0.1mm-0.32mm
• Max Wire Speed：2000m,Min
• Max Dies No.：24
• Spool Bobbin Size：300*215*270mm
• Max Loading Capacity：50kg
• Dimensions：3*2.5*2.3m
• PLC：Siemens
• PLC System：Siemens
• Button：Sch
• Bearing：NSK
• Die：Made in China
• Direstion：Right Hand
• Color：Blue
• Delivery：60 Working Day
• Transport Package：Wood Package
• Specification：CE ISO SGS
• Trademark：HOOHA
• Origin：Dongguan
• HS Code：8463102000
• Production Capacity：20 Sets,Month

Team of HOOHA serviceNameeducationPositionMainly responsible for projectSpecializing in project Industry working history    ( year )zanyang XiecollegeGeneral EngineerThe total project design and planning power cable machine15xioahua HucollegeVis general engineerThe total project design and planning network cable,data cable machine10Chnaghong ChengcollegeEngineerDrawings and after-sales serviceTeflon,Optical fiber cable machine25xiuwu ChencollegeGeneral EngineerThe total project design and planning copper drawing machine15lixin YuancollegeEngineerThe project design and planning coppwer wire making technical16zhenghai Qiucollegecable engineerAfter servicecable making and cable factory management servie15jinxin LiucollegeMarketing engineerAfter serviceelectrical engineer7xingguo TangHigh schoolElectrical engineerAfter serviceelectrical engineer10changqiang LiHigh schoolMaintain engineerAfter servicemachina maintain and install service10haipin LiUniversityEngineering director Marketing and salesproject consulting 12sen YangUniversityEngineering translatorMarketing and salesproject consulting 9




2.fine drawing machine specifications


No.	Items	Feature
1	Wire Inlet Diameter	0.5~1.2 MM
2	Wire Outlet Diameter	0.1~0.32 MM
3	Production Speed	Max 2000 M/Min
4	Final capstan Diameter	250 MM
6	No. of Dies (Channel)	24
7	Dies Outer Size	25mm × 8 - 12mm (thickness)
8	Mechanics Elongation (%)	By the dies from the 1st to 23rd, 13% By the 24th die, 8.7%
9	Main Motor Power	AC 15 KW
12	Drawing Coolant Mode	Full Immersion
13	Electrical System	Including control Cabinets, Operation Panel, Touch Screen, IC, Software

No.	Items	Feature
1	Wire Size range of Annealing	0.1~0.5 MM
2	Annealing Method	DC contact type/triangular annealing system/fully automatic follow up control
3	Max. annealing DC current	300 A
4	Max. annealing DC voltage	57 V
5	Capacity of annealer transformer	21 KVA
6	Power of Steam Generation	6 KW
7	Steam consumption	6-9kg/h, 0.2-0.3MPa
8	Air consumption	15-25 m3/h, 0.4-0.6MPa

No.	Items	Feature
1	Max. Coiling Speed	2000 M/Min
2	Take-up reel	Φ300mm, max
3	Take-up volume	50kg, max
4	Take Up Motor	AC 4 KW
5	Take-up control	Weight type tension bar,automatic modification and control of take-up tension

3.Spare Parts Brands:
Motor: Siemens
Inverter : Japan Yaskawa, Siemens, Taiwan Teco
Temperature Control Meter: Japan RKC;
Auxiliary Relay: Japan Omron ;
Ammeter and Voltmeter: Taiwan Risesun ;
Indicator, Switch and Button: Taiwan TEND ;
Contactor: Taiwan Shihlin
Line Speed Meter: Taiwan FOTEK/Yangming
Bearing : NSK

4.After service
1).Delivery dates: 60 days
2).Payment: TT or L/C
3).Packing: Wood packing and PE plastic packing ensure the goods safety on the transportation.
4). Install and training service: 2 professional engineers who has over 5 years overseas install and cable manufacture training experience.
5) after service phone number online



5. Where are we
Hongkong airport to Humen by boat 2 hours
Guangzhou airport to Humen by car 2 hours
Shenzhen airport to Humen by car 1 hour
Guangzhou South high speed train station to Humen 20 minutes
Shenzhen North high speed train station to Humen 20 minutes.



6. do you have some video of the machine to display how it works ?
A. yes , we have displayed video at the youtube channel : tiezhong chi / HOOHA CO.,LTD
