• Model NO.：YLSK-1280
• Origin：Dongguan
• HS Code：8463300000
• Production Capacity：600 Sets,Year

Basic Info.

Model NO. YLSK-1280 Origin Dongguan HS Code 8463300000 Production Capacity 600 Sets/Year

Product Description

TECHNICAL PARAMETERS:


Model	YLSK-1240	YLSK-1250	YLSK-1260	YLSK-1280
(mm) Machining wire diameter	Ø0.8~Ø4.0	Ø1.2~Ø5.0	Ø2.0~Ø6.0	Ø3.0~Ø8.0
Axis Count	11 Axis	11 Axis	11 Axis	11 Axis
Max feeding Length	Unlimited	Unlimited	Unlimited	Unlimited
Program Storage	999 Max	999 Max	999 Max	999 Max
Instruction value of wire feed	±0.01~±9999.99mm	±0.01~±9999.99mm	±0.01~±9999.99mm	±0.01~±9999.99mm
Instruction value of cam	±0.10~±359.90	±0.10~±359.90	±0.10~±359.90	±0.10~±359.90
(kw) Servo motor of wire feed	5.5	5.5	7.0	11.0
(kw) Servo motor of cam	8×1.2	8×1.5	8×2.7	8×2.7
(kw) Servo motor of Quill (z-axis) servo	1.0	1.5	1.5	1.5
(kw) Servo motor of wire rotation	2.7	2.7	4.5	4.5
(kw) Servo motor of Coiling Spinner (Optional)	1.0	1.2	1.5	1.5
Machine size (LxWxH) (mm)	2400×2000×1900	2800×2200×2200	3100X2450X2500	3100X2450X2500
Weight (kg)	3500	4200	6500	7000
power	380V 3-Phase	380V 3-Phase	380V 3P	380V 3P



We uphold "Honesty, Responsibility, Prudently, Technological Advancement" as principle, and lead our brand go to the future and go to the world.

FAQ
1. Q: Can you customize the machine for the customer?
  A: Yes,we can.We also provide OEM for customer,if you need customize service,please contact us.

2. Q: What is the Min.Order?
  A:  One set.

3. Q: What is the payment term
  A: The payment term is 30% deposit as PO confirmation ,and 70% before the shipment.We also accept other payment term.

 Q: What is the delivery time?
  A: Normally the delivery time of the machine is 15-20 days after receiving deposit.But it depends on machine model. Some of them could be shipped within 10 days.

5. Q: What is the guarantee period of the machine?
  A: The guarantee period is one year from the date of B/L.
