Aluminium Longspan Cold Roll Forming Machine

Hangzhou Zhongyuan Machinery Factory
  • Type：Rolling Machine
  • Forging Forming Method：Cold Roll Forming
  • Power Source：Electric
  • Feature：Automation
  • Certification：ISO9001, CE
  • Warranty：12 Months

Base Info

  • Model NO.：ZYYX
  • Customized：Customized
  • Advantage：Use Widely
  • Condition：New
  • Certificate：CE
  • Operation Language：English or as Per Client`S Required
  • Rollers Material：No.45 Forged Steel with Hard Chrome
  • Cutter Material：Cr12 Mould Steel with Quench Treatment
  • Cutting Style：Automatic Cut to Length
  • Shafts for Rollers：Grand Twice, ID72mm Solid Steel
  • Guarantee：First Year Free, Lifetime Services
  • Cotrol System：Mitsubishi PLC & Converter
  • Machine Color：7.5kw
  • Quality System：ISO9001
  • Transport Package：1*40gp Container for One Machine
  • Specification：CE SGS BV
  • Trademark：zhongyuan
  • Origin：China
  • HS Code：84552210
  • Production Capacity：20sets,Month

Description


                           Aluminium longspan cold roll forming machine ItemSpecification
Raw MaterialTypePre-painted steel coil & galvanized coilsThickness(mm)0.3-0.7Yield strength(mpa)235-550Roller material45# steel , coated with ChromeShaft for rollers Solid shaft with 72mm,processed with cylindrical grinderForming speed(m/min)About 20-25Output speed(m/min)About 12 for 6m length sheetSpeed adjusting modeMitsubishi frequency transformerRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mould steelLength measurementNemicon EncoderControl modeMitsubishi PLCOperating modeButton + Mitsubishi Touch screenMain motor power(kw)7.5KWTotal power(kw)9.9 KW

Feeding & guiding device1setMain roll forming machine1setHydraulic cutting system1setControlling system1setRun out table (auto. Stacker for option)1set

Process flow
Decoiler -- Feeding & Guiding -- Roll forming---Hydraulic Cutting - product to run out table


Why us?Aluminium Longspan Cold Roll Forming Machine
Aluminium Longspan Cold Roll Forming Machine
 About usWe are professional in making roll forming machines since 2003. Company occupies 6650, in which 5650 for workshops.1.  Capacity: 12-15 sets/month 2.  Delivery: in only 5-8 weeks for urgent order 3.  Have our own tool center. 12 sets CNC machines.4. Zhongyuan is a "All-in-house source"     --from raw material to the final high-precision forming machine. We have our precise tooling center.5.  You can rely on our team!       We have engineers with experience more than 15 years in metal forming industry.  Get Free:Provide profile drawing & design technical support FOR FREE!
