• Model NO.：as the drawing
• Application Range：Work Roll, Medium Roll, Back up Roll, Plate Mill,
• Transport Package：Woodern Case
• Specification：Export package
• Trademark：FANGLE
• Origin：China
• Production Capacity：60000tons,Year

Basic Info.

Model NO. as the drawing Application Range Work Roll, Medium Roll, Back up Roll, Plate Mill, Transport Package Woodern Case Specification Export package Trademark FANGLE Origin China Production Capacity 60000tons/Year

Product Description

   Because of the high rolling speed and precision, Sendzimir mill is much more popular  among some high-end users and used for rolling ultra-thin strip,silicon steel, stainless steel,etc. The rolls of Sendzimir mill are made of tool steel, abrasive steel and high speed steel.

   In the manufacturing process, higher quenching and tempering temperatures are usually required. In order to meet the hardness requirements, secondary tempering is required.

   Hardness range of products:55-60 HRC, 60-63 HRC, 61-64 HRC,63-66 HRC,etc.


 Main Technical Parameters:

product name	hardness range	quenching depth	Hardness uniformity
Working Roll	60-66HSD	≥10mm	+/-1 HSD
Intermediate Roll	55-60HSD	≥15mm	+/-1 HSD



Description and tech data:

Material	Mill Type	Roll Type	Hardness
Cr12MoVCo Cr12Mo1V1 (D2)	Sendzimir 12-Hi CR mill	WR	60-64 HRC
5H12 H12	Sendzimir 12-Hi CR mill	First IMR	50-62 HRC
5H12	Sendzimir	Second IMR	50-62 HRC
