• Model NO.：HT
• Wire Diameter：0.8-2.5mm
• Welding Width：600-2000mm
• Rated Capacity：65kvax4
• Dimensions：3350X1800X1400mm
• Certification：ISO9001
• Transport Package：Plastic Bag, Also Can Made as Your Request
• Specification：wire diameter: 0.8-2.5mm
• Trademark：hengtai
• Origin：China
• HS Code：8463300000
• Production Capacity：15 Sets,Month

Size of mesh (mm)
12.7-101.6 (1/2"-4")
Width (mm)
914.4-1219.2 ( 12"-48")
Diameter of wire (mm)
Dia.0.63-Dia.2 ( BWG23-BWG14)
Max. rolled net size (mm)
120 (400')
Welding speed ( mesh/minute)
65 ( radia)
Power
380/220V
50-60HZ
50KWAx4
Outside size(mm)
2600x1700x1350

Peculiarity: Big box-style support, high stability, lower noise, E-Machine in one, straighten & send wire automatically. Used for welded wire mesh of big width & wire dia.
Size of mesh (mm)
25.4-152.4 (1"-6")
Width (mm)
1219.2,1524,1828.8 (48", 60", 72")
Diameter of wire (mm)
Dia.1.07-Dia.2 ( BWG19-BWG14)
Max. rolled net size (mm)
91.4m (300')
Welding speed ( mesh/minute)
45 ( radia)
Power
380/220V;50-60HZ;50KWAx6
Outside size(mm)
3350x1800x1400
Peculiarity: Shuttle sending weft wire type, sending quicker, lower noise, more stable, save electricity. Used for welding net of wire diameter 0.45, diameter 1.07, mesh 1/4" -1/2".
Size of mesh (mm)
6.35-12.7 (1/4"-1/2")
Width (mm)
914.4-1219.2 (12"-48")
Diameter of wire (mm)
Dia.0.45-Dia.1.07 ( BWG25-BWG19)
Max. rolled net size (mm)
120m (400')
Welding speed ( mesh/minute)
75 ( radia)
Power
380/220V;50-60HZ;50KWAx4
Outside size(mm)
2350x1820x1700

Contacts


If you need to buy wire mesh making machine for increasing production or you want to start new business for wire mesh making,welcome discussing with us.


Our machine is popular in India, United state,Pakistan,Kenya,Egypt,Russia,Uzbekistan,Mexico, Brazil, Australia, Thailand, Korea, Saudi Arabia, Morocco, Algeria,etc.



24 hours after sales service

Technical assistance

Adjustable mesh width

Keep safety of operator



Below information is needed for quick quotation



Dear sir/madam, if you are intrested in our machines, you can inquiry me with Product parameters as following, and I will give the  reasonable price.

1. Wire diameter: ________mm ( adjustable )
2. Mesh Size: ________ mm²   ( adjustable )
3. Mesh width: ________ mm ( customized )
4. Industrial voltage : ________380V 50HZ ( customized )
5. Other requirements: .________
