Changeable Galvanized Steel C Purlin Roll Forming Machine Price

Hangzhou Zhongyuan Machinery Factory
  • Type：Mechanical Press
  • Forging Forming Method：Cold Roll Forming
  • Power Source：Electric
  • Feature：Automation
  • Certification：ISO9001, CE, SGS, BV, CE
  • Warranty：12 Months

Base Info

  • Model NO.：ZYYX Series
  • Customized：Customized
  • Advantage：Easy to Maintenance
  • Condition：New
  • Name：C Purlin Roll Forming Machine
  • Power：5.5*4kw
  • Voltage：380V,3phase,50Hz
  • Forming Speed：About15-20m,Min
  • Shaft Diameter：82mm
  • Rollers Material：Cr12 Mould Steel with Quenched Treatment
  • Shafts Material：High Grade No.45 Carbon Wrought Steel
  • Cutting Blade：Cr12 Mould Steel with Quenched Treatment
  • Electric Elements：Mitsubishi PLC and Transducerr
  • Operation Language：English or as Per Client`S Required
  • Transport Package：1*20gp&1*40gp
  • Specification：CE SGS BV
  • Trademark：zhongyuan
  • Origin：China
  • HS Code：84552210
  • Production Capacity：5sets,Month

Description

MaterialTypegalvanized steel sheetThickness(mm)Roller material45#Chrome steelForming speed(m/min)About 15-20m/minSpeed adjusting modeAC FrequencyRoller drive                                            Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter materialCr12 mold steelLength measurementEncoderControl modeMitsubishi  PLCOperating modeButton + Mitsubishi Touch screenMain motor power(kw)5.5*4 KW   (Depend on final design)Machine weightAbout 22000kgsMachine sizeAbout 12m x 2.10m x 1.65m  (Depend on final design)
ComponentsDecoiler1setFeeding & guiding device1setPre-cutting device1setMain roll forming machine1setPunching equipment1setHydraulic cutting system1setPLC Controlling system1setRun out table1set


Process flow:
Decoiling the sheet → Leveling sheet→ Roll forming→ Punching--Measure length and cutting→ the Purlin to the supporter



Controller:
Controller is the "CPU" of forming machine. We choose Mitsubishi PLC from Japan.
With touch screen mode, let your workers enjoy the easy operation;
With auto working mode, let your workers free their hands!


About us
We are professional in making roll forming machines since 2003. Company occupies 6650, in which 5650 for workshops.

1.  Capacity: 12-15 sets/month
2.  Delivery: in only 5-8 weeks for urgent order
3.  Have our own tool center. 12 sets CNC machines.
4. Zhongyuan is a "All-in-house source"
     --from raw material to the final high-precision forming machine. We have our precise tooling center.
5.  You can rely on our team!
      We have engineers with experience more than 15 years in metal forming industry.
Changeable Galvanized Steel C Purlin Roll Forming Machine Price

Get Free:
"Send" below get profile drawing & design technical support by our 15 year experience technicians FOR FREE!
