• Model NO.：CUT60
• Name：Plasma Cutting Machine
• Mosfet：20PCS
• Diodes：16PCS
• Capacitor：4PCS
• Transport Package：Carton
• Specification：550x205x368mm
• Trademark：As required
• Origin：Shenzhen China
• HS Code：84569010
• Production Capacity：30000PCS,Month

Basic Info.

Model NO. CUT60 Name Plasma Cutting Machine Mosfet 20PCS Diodes 16PCS Capacitor 4PCS Transport Package Carton Specification 550x205x368mm Trademark As required Origin Shenzhen China HS Code 84569010 Production Capacity 30000PCS/Month

Product Description

Plasma cutting machine product Characteristics:
*Adjustable cutting current,satisfy different requirement of material,thickness,cutting speed.esthetic cutting area.
*Plasma cutting machine can be used to cut carbon steel,stainless steel,galvanized steel,copper,aluminum etc.
*Buildin default phase protection,over and low voltage protection,over heat protection,and low pressure of compressed air protection etc,make the machine work reliably.
*Plasma cutting machine easy to operate, flat,smooth cutting area.

Model	CUT-60
Input power Voltage Frequency(V,Hz):	AC380(three phase)±15%,50/60
Rated input power capacity(KVA):	7.9
No-load voltage(V):	238
Output current range.(A):	20-60
Rated output voltage(V):	104
Duty cycle (%)(I25ºC):	60
No-load loss(w):	40
Arc-starting:	touch
Efficiency(%):	85
Power factor (COSφ):	0.93
Insulation class:	F
Weight(KG):	23
Overall dimension(mm):	500×263×421
Case protection degree:	IP21S
Air compressor displacement(S):	0.25
Max cutting thickness(mm):	25
