Automatic High Speed Bonnell Spring Coiling Machine (SX-80is)

Guangzhou Xidengbao Mattress Machinery Co., Ltd.
  • Control Type：Automatic
  • Production Speed：80 Springs,Minute
  • Spring Coils：4-7 Coils
  • Automatic：Yes
  • Spring End Ring：62-95mm
  • Steel Wire Gauge：1.8-2.4mm

Base Info

  • Model NO.：SX-80is
  • Spring Height：80-190mm(Option-210mm)
  • Convolutions：4-7turns
  • Main Drive Power：4kVA
  • Swift Frame Power：2.2kVA
  • Heat Treatment：10kVA
  • Transport Package：Plywood Pallet
  • Trademark：XIDENGBAO
  • Origin：China(Mainland)
  • HS Code：8463300000
  • Production Capacity：20 Sets , Month

Description

Basic Info.

Model NO. SX-80is Spring Height 80-190mm(Option-210mm) Convolutions 4-7turns Main Drive Power 4kVA Swift Frame Power 2.2kVA Heat Treatment 10kVA Transport Package Plywood Pallet Trademark XIDENGBAO Origin China(Mainland) HS Code 8463300000 Production Capacity 20 Sets / Month

Product Description

SX-80is Automatic Bonnell Spring Coiling Machine
1. High speed running
2. Brand: Xidengbao
3. Spring type: Bonnell spring

Product Description:
SX-80IS High Speed Bonnell Spring Coiling Machine is an auto machine that is making mattress springs. It combines coiling, knotting, heating and outputting total four procedures in one machine. The speed is at 80 springs one minute. The coiler SX-80I utilizes a fully integrated computerized Programmable logic controller (PLC) and servo control system. All machine functions include wire feeding length, knotting, heat treatment, lubrication and self-protecting are automatically controlled.
Both the electrical parts and the structure of the machine are up to the CE. So that it is more safe and user-friendly.

Technical Characteristics:
1. High capacity with minimum space requirements - up to 38'000 Bonnell Springs / 8 hours.
2. Rapid change-over.
3. Easy operation and short training period thanks to clearly structured concept with integrated control unit.
4. Works without compressed air.
5. Top quality and ease of use.

Technical specification:
Spring TypeBonnell
Production Speed80 Springs/Minute (adjustable)
Diameter Adjustment+ / -1mm
External Spring Diameter62-95mm
Spring Height80-190mm (option: 190-210mm)
Spring Wire Diameter1.8-2.4mm (option: 2.5mm)
Spring Coils4-7 Coils
LubricationFully Automatic Standard
TemperingStandard
ControlPLC
SafetyCoiler Sound Enclosure and other features
Power Requirements380V/220V 50HZ/60HZ
Main Drive Power4KVA
Swift Frame Power1.5KVA
Heat Treatment10KVA
Machine weight
2800KG
