- Model NO.:CRM
- Transport Package:Plywood and Steel Frame
- Specification:CE
- Trademark:smc
- Origin:Shanghai China
- HS Code:8454309000
- Production Capacity:20set,Month
None scope of supply |
No | Name | Quantity | Description | Note |
1 | big platform | 1pcs | 4columns connecting the medium platform(20# channel steel, drawing supplied by the supplier) | |
2 | Basic of the machine | 1set | For fixing the furnace body and the platform (drawing supplied by the supplier) | |
3 | Wire and cable | 1set | For combining the machines | |
4 | Cable bridge | 1set | size would be according to the actual size when install | |
5 | Water supply system | 1set | Including one 80M³ water pool, two 5.5 kw pump (one for spare), water pipe (till the machine), return water pipe( from machine to the return water tank, and from the water tank to the water pool), emergency water tower, and emergency water supply | |
6 | Generator | 1 set | Capacity: 150KW (backup when power stop) | |
7 | Power supply system | | 380V three-phase five-wire | |
Annex 2
One year consumable list for SYJ0408-I3(None scope of supply)
No. | Name | Specification | unit | Qty |
1 | Graphite die | φ8mm | pcs | 5ton / pc |
2 | Graphite protect sleeve | φ8mm | pcs | 5ton / pc |
3 | Insulation sleeve | φ8mm | pcs | 5ton / pc |
4 | Crystallizer | φ8mm | pcs | 250ton / pc |
5 | Crystallizer inner tube | φ8mm | pcs | 250ton / pc |
6 | Water jacket | | pcs | 2pcs/year |
7 | Coil | | pcs | 2pcs/year |
8 | Copper channel | | pcs | 2pcs/year |
9 | Quartz sand | Mix sand | ton | 3.5ton/year |
10 | Mold brick | | set | 1set/year |
11 | Straight light brick | | set | 1set/year |
12 | Wedge-shaped light brick | | set | 1set/year |
13 | Fiber board | δ=20mm | case | 2box/year |
14 | Asbestos plate | δ=5mm | case | 1box/year |
15 | Quick connector | DG15 | pcs | 10pcs/year |
16 | Fiber glass | | coil | 100coil/year |
17 | Hose assembly | 1600mm | pcs | 10pcs/year |
18 | Charcoal | | kg | 5kg/ton |
19 | Graphite flake | 3299 | kg | 0.5kg/ton |
