• Model NO.：ZYYX100-300
• Customized：Customized
• Advantage：Easy to Maintenance
• Condition：Used
• Name：C Purlin Making Machine
• Model Number：Zyyx120-400
• Voltage：380V,3phase,50Hz
• Thickness：1.5-4.0mm
• Coil Width：391-671mm
• Main Power：5.5*4kw
• Shaft Diameter：82mm
• Brand Name：Zhongyuan
• Total Weight：About 22000kg
• Roller Material：Cr12 Mould Steel Being Quenched Treatment
• Transport Package：1*20 &1*40FT Container
• Specification：CE SGS BV
• Trademark：zhongyuan
• Origin：China
• HS Code：84552210
• Production Capacity：10sets,Month

Technical parametersItemSpecification
Raw MaterialTypegalvanized coilsThickness(mm)1.5-4.0Yield strength(mpa)235-350Roller materialCr12 mould steelHardness of rollers HRC58-60Shaft for rollers Solid shaft with 82mm,processed with cylindrical grinderForming speed(m/min)About 10-15Speed adjusting modeMisubishi frequency transformerRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mould steelLength measurementNemicon EncoderControl modeMitsubishi PLCOperating modeButton + Mitsubishi Touch screenMain motor power(kw)About5.5*4KW
Process flow
Decoiler -- Feeding & Guiding -- Roll forming---Hydraulic Cutting - product to run out table


About us
1. Customize roll forming machines since 2003.
2. CE, ISO certificate by SGS.
3. Mitsubishi PLC controller and transducer from Japan
4.12moths warranty, lifetime technical support
5. Capacity: 12-15 sets/month
6. Delivery: In only 5-8 weeks for urgent order
7. Company occupies 6650m2, in which 5650m2 for workshops
8. Have our own tool center. 12 sets CNC machines.
9. Third party inspection: Bureau Veritas, SGS. Can provide assessment report.
10. Machine original brand: Zhongyuan
11. Set up business relationship with companies in more than 20 countries
