Xuanen Middle Speed Scroll Cutting Line Xe1100hb3-120

Anhui XuanHong CNC Technology Co., Ltd.
  • Customized：Customized
  • Layout：Vertical
  • Cutting Material：Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel
  • Power Source：Electric
  • Cutting Thickness：0.15~0.5mm
  • Cutting Width：600~1100mm

Base Info

  • Model NO.：XE1100HB3-120
  • Cutting Length：460~1200mm
  • Frequency：120cuts,Min
  • Cutting Linear Velocity：10-100m,Min
  • Length Tolerance：≤±0.25mm,M
  • Transport Package：Standard for Export
  • Specification：SGS
  • Trademark：xuanen
  • Origin：Zhejiang Hangzhou
  • Production Capacity：50 Set

Description

Basic Info.

Model NO. XE1100HB3-120 Cutting Length 460~1200mm Frequency 120cuts/Min Cutting Linear Velocity 10-100m/Min Length Tolerance ≤±0.25mm/M Transport Package Standard for Export Specification SGS Trademark xuanen Origin Zhejiang Hangzhou Production Capacity 50 Set

Product Description





Xuanen Middle Speed Scroll Cutting Line XE1100HB3-120

 I.Brief Introduction
This scroll cutting line is a special equipment to decoil, level,
shear the coil material of tinplate and aluminum coils.
It is an important equipment to reduce the production cost
by decreasing the waste of coil material in making iron tank and cover.
Adopting this scroll cutting line can help you to save coil material with 3%-8%.
It consists of decoiler, leveler, scroll cutter, belt conveyor,
 three material receiving platforms, pinhole detector and electric control cabinet.
This line can produce different products with one machine only
by changing corresponding dies with an automatic die changing system.
The cutting frequency is 120times per minute. It is also provided with a pinhole detector device-Photomultiplier pinhole detector which can detect the pinhole in high accuracy..
 2.Main technical parameters
Cutting materialstinplate, aluminum band
Cutting thickness0.15~0.5mm
Cutting width600~1100mm
Cutting length460~1200mm
Cutting frequency120cuts/min
 Cutting linear velocity10-100m/min;
Stacker loaded weight2T
Height of stacker460mm
 Length tolerance≤±0.25mm/m
Diagonal tolerance≤±0.15mm
Decoiling expansion rangeφ380~φ450mm orφ450~φ520mm
Maximum OD of coil materialφ1800mm
Maximum weight of coil material10T







3.Feature:
1. High speed decoiler with cantilever support, adopting ground recoiling
 to save the heavy labor of excavating a pit.
2. Precise gauge, good cutting quality and high production efficiency.
3. No need for material pit, save foundation cost.
4. Belt conveyor has flap institution which is much easier for user to change the mould.
