High Speed Cut to Length Machine Xe1200bh4-180
Anhui XuanHong CNC Technology Co., Ltd.- Cutting Thickness：0.15~0.5mm
- Cutting Width：600~1200mm
- Cutting Length：460~1200mm
- Max Coil Weight：13.5t
- Max Coil Dia：D 1800mm
- Cutting Frequency：180times,Min
Base Info
- Model NO.：XE1200BH4-180
- Cutting Linear Velocity：150 M,Min
- Stacker Height：460mm(Including Bracket)
- Item No.：Xe1200hb4-180
- Stacker：4
- Transport Package：Film
- Specification：SGS
- Trademark：XuanEn
- Origin：Hangzhou
- HS Code：8462319000
- Production Capacity：30 Set
Description
Basic Info.
Model NO. XE1200BH4-180 Cutting Linear Velocity 150 M/Min Stacker Height 460mm(Including Bracket) Item No. Xe1200hb4-180 Stacker 4 Transport Package Film Specification SGS Trademark XuanEn Origin Hangzhou HS Code 8462319000 Production Capacity 30 SetProduct Description
Picture:
Product DescriptionXE1200HB4-180 High Speed Scroll Cutting Line
Application: The line is suitable for tinplate decoiling, leveling and cutting. It is an important device in making iron tank and cover which can save material waste and production cost.
Construction: It consists of hydraulic decoiler, charge hoist, decoiling rack, leveler, feeding rack, scroll cutter, output conveyor, four stacker, hydraulic lifting platform, roll gang, hydraulic components and electric control cabinet.
Feature:
1. High speed decoiler with cantilever support, adopting ground recoiling to save the heavy labor of excavating a pit.
2. Precise gauge, good cutting quality and high production efficiency.
3. No need for material pit, save foundation cost.
4. Scroll cutter adopting hydraulic die clamper and changing die by side, which can raise working efficiency.
5. Stacker adopting output mechanism like lamination, greatly accelerate linear velocity and increase the capacity.
| ITEM NO. | XE1200HB4-180 |
| NAME | High Speed Scroll Cutting Line |
| CUTTING MATERIAL | TINPLATE |
| CUTTING THICKNESS | 0.15~0.5mm |
| CUTTING WIDTH | 600~1200mm |
| CUTTIGN LENGTH | 460~1200mm |
| MAX COIL WEIGHT | 13.5t |
| MAX COIL DIA | Φ1800mm |
| DECOILING EXPANSION RANGE | Φ405/Φ505 |
| CUTTING LENGTH TOLERANCE | ≤±0.25mm/m |
| DIAGONAL TOLERANCE | ≤±0.15mm |
| CUTTING LINEAR VELOCITY | 150m/min |
| CUTTING FREQUENCY | 180times/min(WHILE CUTTING LENGTH IS 800MM) |
| STACKER LOADING WEIGHT | 2t |
| STACKER HEIGHT | 460mm(INCLUDING BRACKET) |
| STACKER | 4 |
| CAPACITY | 69T/SHIFT |
