Vertical H Beam Steel Structure Flange Hydraulic Straightening Machine Straightener
Wuxi Lemar Machinery Equipments Co., Ltd.- After-sales Service：Online Video Instruction
- Type：H Beam Flange Straightening Machine
- Usage：H Beam Flange
- Voltage：380V-440V
- Automatic Grade：Automatic
- Principle：Deformation After H Beam Welding
Base Info
- Model NO.：JZJ-50
- Certification：CCC, ISO9001, CE
- Warranty：12 Months
- Customized：Customized
- Condition：New
- Function：Straightening for H Beam Flange Plate
- Straightening Mode：Hydraulic
- Max Flange Thickness：50mm
- H Beam Material：Q235
- Power：Customized
- Suitable for H Beam Length：12m
- Flange Width：200-800mm
- Input Roller Length：9m
- Output Roller Length：9m
- Colour：Customized
- Roller Material：35CrMo
- Hydraulic Station：1 Set
- Roller Hardness：HRC50-55
- Straightening Wheel Speed：≥8.9m,Min
- Delivery：45 Days
- Transport Package：Nude
- Trademark：Lemar
- Origin：Wuxi, China
- HS Code：8462291000
Description
1.The maximum thickness of the correction wing plate is 40mm (material Q345) 50mm(material Q235);
2.The input and output rollers are each 3 meters/section*2 sections;
3.The main motor power is 11KW, and the correction speed is ≈7.8m/min.
4.Applicable to the width of the wing plate 150-800mm and the height of the web plate above 350mm (a pair of small pressure rollers are additionally provided, which can meet the height of the web plate between 180-350mm and the thickness of the flange plate ≤12mm);
Specification:
Parameters in the table of welded H-beams for rectification:
Note: The thickness and width must conform to the table below, and the material is Q345.
Other Matters:
1. User Instructions
The power cord from the user's power supply point to the device is provided by the user. When the equipment is installed, the lifting capacity is not less than 20 tons.
Users need to make equipment foundation and self-made parts according to the basic drawings and self-made parts drawings provided by our company. For the rest, please complete the relevant supporting requirements according to the "preparation work before commissioning and installation" provided by our company.
2. Product manufacturing acceptance specification
The products are checked and accepted in accordance with the technical agreement signed by the buyer and the seller.
2.The input and output rollers are each 3 meters/section*2 sections;
3.The main motor power is 11KW, and the correction speed is ≈7.8m/min.
4.Applicable to the width of the wing plate 150-800mm and the height of the web plate above 350mm (a pair of small pressure rollers are additionally provided, which can meet the height of the web plate between 180-350mm and the thickness of the flange plate ≤12mm);
Specification:
Parameters in the table of welded H-beams for rectification:Note: The thickness and width must conform to the table below, and the material is Q345.
Other Matters:
1. User Instructions
The power cord from the user's power supply point to the device is provided by the user. When the equipment is installed, the lifting capacity is not less than 20 tons.
Users need to make equipment foundation and self-made parts according to the basic drawings and self-made parts drawings provided by our company. For the rest, please complete the relevant supporting requirements according to the "preparation work before commissioning and installation" provided by our company.
2. Product manufacturing acceptance specification
The products are checked and accepted in accordance with the technical agreement signed by the buyer and the seller.
